Resin Flooring - Degafloor Free Flow System

Verified by manufacturer 2 months ago

Degafloor Ltd Third party certifications:
  • BREEAM - Certification

    Certificate type

  • European Technical Approval (ETA)

    European Technical Approval (ETA)

    Certificate type

  • QMS ISO 9001

    QMS ISO 9001

    Certificate type

  • UK Conformity Assessed (UKCA)

    UK Conformity Assessed (UKCA)

    Certificate type

A self-levelling flow applied resin system

Jump to:
BIM object icon
+44 (0)1778 342545 Website

Application

Suitable for the most demanding of areas, such as chemical and pharmaceutical production.

Description

A self-levelling flow applied system.


Combines methyl methacrylate (MMA) resin and fine aggregate. The system is pigmented to create a solid and stable colour with a smooth finish.


Available in a wide variety of colours and specification for installations where colour differentiation and demarcation between areas are important, such as manufacturing, distribution and warehouse areas.


Features and benefits:

  • Durable, fully encapsulated system.
  • Installation - fully cured within two hours at temperatures as low as -20°C.
  • Bonds to existing subfloors.
  • Seamless and impermeable surface without pinholes or air bubbles.
  • Tailored decorative slip resistant finishes.
  • Resistant to UV light, weathering and temperatures up to 80°C.
  • Manufactured in accordance with BS EN ISO 9001:2015 Certificate 20/Q064 Quality Management Systems.

General information

Color

Beige

Blue

Brown

Green

Grey

Show more

Finish

Smooth

Material

Methyl methacrylate

Methyl methacrylate resin.

Shape

Formless

WarrantyDescription

Ten year

Uniclass

Ss_30_42_54_75 Resin flooring systemsPrimary

CAWS

M12/110 Resin flooring

M12/10 Resin flooring

Specification data - Resin flooring systems

System performance

Watertight and impervious to moisture.

Substrate

-

Testing

Bond, moisture and compressive tests undertaken by the Degafloor Approved Installer.

For the Warranty process, prior to installation.

Preparation

Dependant on substrate, ie metal, concrete, timber, asphalt.

Undertake mechanical floor preparation prior to application of primer.

Primer

Dependant on the substrate, i.e. cementitious, metal, timber, asphalt, tiles. Consult manufacturer and insert requirements.

-

Resin skirtings and upstands

To match flooring system and colour.

Abrasion resistance

Weight loss <3000 mg.

Adhesion strength

≥2.0 N/mm².

Bond strength

≥B2.0

Capillary absorption

W <0.1 kg/(m²·h^0.5).

Capillary absorption and permeability to water.

Carbon dioxide permeability

SD >50 m.

Chemical resistance

Reduction in hardness <50%.

Colour

Agate Grey.

Beige.

Blue Grey.

Chocolate Brown.

Fast Blue.

Show more

Curing time

Two hours.

Finish

Smooth.

Impact resistance

Class I, ≥IR 4.

Material

MMA.

Methyl methacrylate resin.

Reaction to fire

Not tested.

Release of corrosive substances

SR.

Standard

To BS EN 1504 and BS EN 13813.

Third-party certification

To British Board of Agrément-certified (20/Q064).

Water vapour permeability

Class III.

Wear resistance

≤AR 0.5

Environmental information

Contains Red List materials

No

Country of material origin

Germany

Country of product manufacture

Germany

BIM objects

BIM object icon

NBS BIM object standard

This BIM object has been authored to meet the requirements of the NBS BIM object standard.

Find out more about the NBS BIM object standard.

Platform Compatible Version
IFC
-

1

Revit
-

2

Case studies

Degafloor Flake System - Arthur Mellows Village College, Resin Flooring

Degafloor Flake System - Arthur Mellows Village College, Resin Flooring

Third party certifications

BREEAM - Certification

BREEAM - Certification

FERFA BREEAM Statement

European Technical Approval (ETA)

European Technical Approval (ETA)

Certificate of Conformance for coating of floors in companies where foodstuffs are treated and processed

QMS ISO 9001

QMS ISO 9001

BS EN ISO 9001 : 2015 Quality Management System

UK Conformity Assessed (UKCA)

UK Conformity Assessed (UKCA)

UK Certificate of Conformity of the Factory Production Control - UK 0836 CPR 22/F6564
