Regal Cycle Shelter

Name: Regal Cycle Shelter
Brand: Broxap Street Furniture
SKU: panhCuqqPDaHKSSDRZGPdq

Verified by manufacturer 27 days ago

BXMW/RG Junior Regal Cycle Shelter

Broxap Street Furniture

Third party certifications:

Health & Safety Accreditation
Certificate type
BBA Agrément Certificate
Certificate type
CHAS
Certificate type
Constructionline
Certificate type
ISO 45001 Health and Safety Management
Certificate type
ISO 9001 Quality Management
Certificate type
Rospa Safety Charity
Certificate type
CQMS
Certificate type
smas WORKSAFE
Certificate type

Regal cycle shelters use the basis of the Wardale design whilst utilising angled front end frames which add a modern look to the traditional design.

Jump to:

BOS

+44 (0)1782 571700 Website

Application

Cycle shelters suitable for providing a covered cycle parking area.

Broxap has long been one of the leading designers and manufacturers of a vast range of cycle parking products including bike storage. With our extensive range of cycle shelters, hubs, compounds, cycle stands and cycle racks, we have a cycle parking solution to suit every budget.

With the increased need for cycle parking equipment and bike shelters in urban areas, we are a leader in the market for space saving and innovative solutions and are always working to find new ways to improve their products and their customer’s experience.

Broxap's cycle parking equipment can contribute towards gaining ENE8 credits when used in the appropriate situation, under the Code for Sustainable Homes.

Our cycle parking products are BREEAM and Code for Sustainable Homes Compliant.

Description

Using modular units the Regal cycle shelter can be linked together to create banks of cycle shelters which allow to you accommodate almost any quantity of bicycles.

The versatility of the Regal cycle shelter means that the shelter can be retro-fitted with extensions at a later date pushing the parking capacity upwards whilst keeping installation costs low.

Features and benefits:

Polycarbonate end panels included.
Robust modular construction featuring load bearing purlins.
Welded end frames and purlin section made from heavy-duty box section assembled with anti-tamper high strength bolts.
Anti-climb end frames.
Adjustable baseplates.
Hot dipped galvanized to BS EN ISO 1461:2009.
4 mm ClearView PEGg UV roof and side cladding (5 mm also available).
BREEAM Compliant Configurations.

Options:

Opal Cladding to Roof and Sides.
Extended adjustable baseplates for submerged fixing.
Helmet lockers.
Powder coated to a wide range of colours.
LED or solar lighting.
Full Installation Service.
Optional Zinc Rich Primer.

Capacities:

3600 mm - 8 Cycles.
4100 mm - 10 Cycles.
5000 mm - 12 Cycles.

General information

Color	Black Blue Green Grey Red White Yellow Show more
Finish	Galvanized Powder-coated Guidance for specification option: Polyester powder coated.
Material	Steel Guidance for specification option: Frame - 60 x 60 mm box section. Polycarbonate Zinc
Shape	Other
Length	4100 mm 3600 mm 5000 mm
Width	2140 mm
Height	2150 mm
Warranty description	One year

Uniclass	Pr_20_65_78_58 Open-sided sheltersPrimary Ss_20_10_70_84 Storage shelter systems
CAWS	B91/340 Cycle shelter B91/330 Canopy B91/385 Shelter

Specification data - Open-sided shelters

Shelter description	Junior Regal Cycle Shelter.
Dimensions	-
Plan size	3600 x 2140 mm. 4100 x 2140 mm. 5000 x 2140 mm.
Height	2150 mm.
Frame	-
Material	Steel.
Finish	Galvanized. Galvanized and polyester powder coated. Zinc rich primer. Guidance for specification option: Optional.
Colour	Cobalt Blue RAL 5013. Goose Grey BS 4800 00-A-05. Holly Green BS 4800 14-C-39. Jet Black RAL 9005. Nimbus Grey BS 4800 10 A 07. Sky Blue RAL 5015. Traffic Red RAL 3020. Traffic White RAL 9016. Traffic Yellow RAL 1023. Anthracite Grey RAL 7016. Manufacturer guidance Powder coated to any standard RAL colour
Roof covering	4 mm PETg UV ClearView (Clear). 5 mm PETg UV ClearView.
Accessories	LED or solar lighting. Opal Cladding to Roof and Sides. Helmet lockers.

Sustainability data

Country of product manufacture	United Kingdom
Material	Steel Guidance for specification option: Frame - 60 x 60 mm box section. Polycarbonate Zinc
Manufacturing plant location	Chesterton, Newcastle ST5 6BD, UK
