Reflex Top Sport Uno
Application

To be installed onto even sub-floors. Suitable for use in various applications.

Description

Flooring understructure, available with area elastic or combined elastic finishing surfaces.

Features and benefits:

  • Low floor height.
  • Fast and easy to install.
  • Manufactured using birch plywood with a unique jointing system.
  • 60% stronger than traditional tongue and groove systems.
  • Will not break down over time.
  • No mechanical fixings are required within the installation process.
  • The top surface needs minimal preparation, and can then accept a range of finishing sports coverings.
  • Can be supplied with FSC® Chain of Custody Certification - consult manufacturer for details.
  • Manufactured in accordance with EN 14904 and DIN 18032.

Composition:

  • Vapour membrane.
  • 15 mm technical foam shock pad/ PUR-foam.
  • Acoustic membrane.
  • Reflex 'TP' joint.
  • 15 mm plywood load distribution panel, glued according to EN 636-2 with a groove and tongue system.

Applications:

To be installed onto even sub-floors. Suitable for use in various applications.

General information

Uniclass 2015

Ss_30_42_72_72 Resilient sheet floor covering systemsPrimary

CAWS

M50/150 Sheeting

M50/20 Sheeting

Specification data - Resilient sheet floor covering systems

Product Reference

Reflex Top Sport Uno

Finishing surface

Area elastic, seamless polyurethane (PU)

Area elastic, sports linoleum

Area elastic, sports vinyl

Area elastic, timber parquet

Combined elastic, 5 mm rubber/ 2 mm PU

Combined elastic, 6 mm cushion/ vinyl

Standard product features

Overall depth:

30 mm.

Technical characteristics:.

  • Sport classification (to EN 14904): Area elastic: A4; combined elastic: C4.
  • Shock absorption: Area elastic: 56%; combined elastic: 59%.
  • Deformation: Area elastic: 33 mm; combined elastic: 4 mm.
  • Ball rebound: 97%.
  • Rolling load: >1500 N, no damage.
  • Friction: 0.82.
