ReadyFloor 155 5 Wire
Verified by manufacturer 8 months ago
Readyfloor 155 mm is ideal for the domestic market and is exclusively used in housing developments.
Application
Suitable for housing developments, retail and light commercial use.
Description
Beam and block construction overcomes many onsite difficulties such as costly excavation and consolidation of backfill prior to the placing of oversite concrete. Readyfloor 155 mm is ideal for the domestic market and is exclusively used in housing developments.
Features and benefits:
- Quick.
- Versatile.
- Fast installation.
- Easy to store.
- Provides immediate working platform.
- Provides all-round durability.
- Cost-effective.
General information
Color | Grey |
Material | Concrete |
Length | Bespoke |
Width | Manufacturer guidanceCross sectional width varies across profile. |
Height | 155 mm |
Uniclass |
Specification data - Concrete beam and block deck systems
Precast concrete beams | Prestressed concrete T-beams. |
Infill blocks | Solid aggregate concrete infill blocks.Guidance for specification option: Infill block size: 440 x 215 x 100 mm (Also compatible with CEMEX Readytherm Insulation and aereated concrete blocks); compressive strength 7.0 N/mm². |
In situ concrete topping | 1:4 cement:sand grout to fill all voids between the beams and blocks. |
System accessories | C-clips, closure blocks, split course blocks; air vents. |
Floor finish | Chipboard and insulation. Sand:cement screed. Screed and insulation. |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 5 |
 IFC | - | 4 |
