Pull Handle Solid Timber Detailed ASH574 - Pull Handle
Verified by manufacturer 4 months ago
32 mm wide handle
32 mm wide handle
Made in Britain
Certificate type
Straight timber door pull handle.
Application
- Aluminium doors.
- Timber doors.
- Glass doors.
- Commercial doors.
Description
A straight all timber door pull handle manufactured from solid timber.
Available in a number of finishes and comes complete with appropriate fixings to suit the door thickness.
These door handles can be manufactured to any specified centres.
General information
Color | Brown Other |
Finish | Oil rubbed Manufacturer guidance7 timber grips available |
Material | Timber |
Shape | Rectangle |
Length | Bespoke |
Width | 32 mm 38 mm Bespoke Manufacturer guidanceStandard widths; maximum distance between centres (length) varies with value specified. |
Height | 85 mm Guidance for specification option: Standard projection. Bespoke |
Warranty description | 20 year |
Uniclass | |
CAWS | P21/42 Pull handles P21/641 Pull handles |
Specification data - Pull handles
Form | Straight. |
Diameter | 32 mm wide.Bespoke. |
Distance between centres | Guidance for specification option: Insert requirements, 500–1000 mm. 150 mm overrun as standard (can be adjusted if required). |
Material and finish | Ash (ASH).Beech (BE).Black Walnut (BW).Iroko (IR).Maple (MP).American Oak (AO).Sapele (SP). |
Colour | As Material and finish. |
Mounting | Guidance for specification option: Fixing configuration dependent on customers requirements. Consult manufacturer for details and insert requirements. |
Projection | 85 mm. Guidance for specification option: Standard. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Europe |
Country of product manufacture | United Kingdom |
Recyclability | Yes |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 95 % |
Third party certifications
Made in Britain
Registered Member of Made in Britain
Literature
ASH574 Product Data Sheet
