Public Roof - Intensive Green Roof Systems

Verified by manufacturer 2 months ago

Driveable - Lorries

Optigreen Ltd Variant:

Intensive green roof systems for roofs that can be walked and driven on.

Jump to:
+44 (0)203 5899400 Website

Application

Designing a public roof is a challenging and complex project. Load distribution, surface water drainage and underground drainage are a few of the main planning issues involved. In addition, the various use categories (U 1–3) also have to be taken into account. Optigrun offer a range of public roofs:

  • Public roof walkable: walkable non-green roof area.
  • Public roof driveable - for passenger cars: non-green roof area accessible to cars.
  • Public roof driveable - for lorries: non-green roof area accessible to trucks.
  • Public roof greenable pavements: walkable greened roof area.
  • public roof gravel lawn: walkable greened roof area.
  • Public roof retention: walkable greened roof area with simultaneous function as retention area.
  • Public roof inverted roof: specially adapted construction method for the realization of traffic areas on inverted roofs.
  • Public roof without slope: for traffic areas on flat roofs without a gradient in the waterproofing layer.


Features and benefits:

  • Combined with green spaces on the roofs.
  • Varying load class depending on use.
  • Used in a range of applications.


Description

Designing a public roof is a challenging and complex project. Load distribution, surface water drainage and underground drainage are a few of the main planning issues involved. In addition, the various use categories (U 1–3) also have to be taken into account. Optigrun offer a range of public roofs:

  • Public roof walkable: walkable non-green roof area.
  • Public roof driveable - for passenger cars: non-green roof area accessible to cars.
  • Public roof driveable - for lorries: non-green roof area accessible to trucks.
  • Public roof greenable pavements: walkable greened roof area.
  • public roof gravel lawn: walkable greened roof area.
  • Public roof retention: walkable greened roof area with simultaneous function as retention area.
  • Public roof inverted roof: specially adapted construction method for the realization of traffic areas on inverted roofs.
  • Public roof without slope: for traffic areas on flat roofs without a gradient in the waterproofing layer.


Features and benefits:

  • Combined with green spaces on the roofs.
  • Varying load class depending on use.
  • Used in a range of applications.

General information

Color

Green

Brown

Black

Finish

Natural

Shape

Square

Rectangle

Other

Length

Bespoke

Width

Bespoke

Height

Bespoke

Uniclass

Ss_45_40_47_40 Intensive green roof systemsPrimary

CAWS

Q37/110 Intensive green roof

Specification data - Intensive green roof systems

Protection

-

Protection layer

Protection, separation and slip layer SGL 500.

Guidance for specification option:

  • Protection, separation and slip layer.
  • Strength class: GRK 5.
  • Thickness: approx. 4.0 mm.
  • Weight: 500 g/m².
  • Roll: 60 m².
  • Roll width: 2.0 m.

Separation layer

-

Manufacturer guidance

Protection, separation and slip layer SGL 500 protects the waterproofing with combined separating and sliding function.

Slip layer

-

Manufacturer guidance

Protection, separation and slip layer SGL 500 protects the waterproofing with combined separating and sliding function.

Moisture control

-

Drainage layer

Protection and drainage board FKD 12.

Guidance for specification option:

  • Nominal thickness: 12 mm.
  • Weight: approx. 1.3 kg/m².
  • Maximum flow capacity: approx. 0.39 l/m×s (with 2% slope).
  • Compression strength: approx. 1600 kN/m² as per EN ISO 25619-2.

Drainage ancillaries

-

Manufacturer guidance

Consult manufacturer for details and insert requirements or omit.

Planting systems

-

Planting medium

-

Manufacturer guidance

Consult manufacturer for details and insert requirements or omit.

Planting requirements

-

Manufacturer guidance

Consult manufacturer for details and insert requirements or omit.

Fire breaks

-

Manufacturer guidance

Consult manufacturer for details and insert requirements or omit.

Edge restraints

-

Manufacturer guidance

Consult manufacturer for details and insert requirements or omit.

Base layer

Base layer of gravel 0–32 mm (minimum height 150 mm).

Guidance for specification option:

Consult manufacturer and insert requirements.

Bedding layer

Suitable bedding material.

Guidance for specification option:

Consult manufacturer and insert requirements.

Cover

Paving.

Guidance for specification option:

  • Plaster layer at least 100 mm high.
  • Surface layer (e.g. interlocking paving, slabs, concrete).
  • Insert requirements.

Manufacturer guidance

Cover layer.

Weight

600 kg/m² (6.0 kN/m²).

Depth

From 300 mm.

Manufacturer guidance

Build-up depth.

Roof pitch

1-5°.

Manufacturer guidance

Roofs with zero degree falls do not meet FLL Green Roof Guidelines and Optigrün systems should not be used without consultation.

Load class

3 (maximum 20 tonne vehicle weight).

System accessories

-

Manufacturer guidance

System add-ons available.

Consult manufacturer for details and insert requirements.

Sustainability data

Country of material origin

Europe

Country of product manufacture

Europe

Literature

Optigrün Technical Brochure

Optigrün Technical Brochure
