PSMX Mobility Scooter Charging Units

Verified by manufacturer 3 months ago

PSMX 1

metroSTOR® (a brand of Streetspace Group) Variant:
Third party certifications:
  • Alcumus SafeContractor

    Alcumus SafeContractor

    Certificate type

  • CHAS

    CHAS

    Certificate type

  • Constructionline

    Constructionline

    Certificate type

  • ISO 14001:2015

    ISO 14001:2015

    Certificate type

  • ISO 9001:2015

    ISO 9001:2015

    Certificate type

  • smas WORKSAFE

    smas WORKSAFE

    Certificate type

Mobility scooter storage and charging unit with extra space, for up to six scooters of any class.

Jump to:
01227 200404 https://streetspacegroup.co.uk/metrostor/

Application

For those applications where users require additional space either for access and egress or a non-standard mobility scooter, metroSTOR PSMX provides a 1600 mm module width. Designed for residential applications.

Description

The metroSTOR PSMX mobility scooter charging and storage unit has a module width of 1600 mm, and a door width of 1200 mm. This variant has been specifically developed for situations where users need additional space to get on and off their mobility scooter – for example where they have to transfer directly from a wheelchair.


Features and benefits:

  • The metroSTOR PSM range is designed to provide users with a secure, easy-to-use storage and charging facility, protected at all times from the elements within a compact footprint. The unobtrusive design means the metroSTOR PSM range can be positioned in accessible locations close to buildings without undue visual impact.
  • The metroSTOR PSM range is manufactured in three product variants from 1050 mm width modules where space on site is restricted, to 1600 mm width for the larger Class 3 mobility scooters or where users will require additional space for access. metroSTOR PSM units can be specified with doors left or right-handed to suit narrow access paths, and are available as CAD blocks/ BIM models for ease of planning and site layout design.
  • This highly flexible specification extends to a class leading choice of panel types including fire-resistant options, enabling the metroSTOR PSM range units to add a welcome architectural impact to a scheme in addition to fulfilling a vital storage function.
  • The metroSTOR PSM range structures are designed and manufactured in the UK by Streetspace under BS EN 9001:2015, BS EN 9001:2015 and BS EN 1090 accredited processes. Hot dip galvanized coating is standard with colour powder coat options. Each unit is supplied with fully tested, factory assembled electrical panels containing IP rated sockets for chargers and PIR activated LED interior lighting; external lighting can be added as an optional extra.


General information

Color

Black

Grey

Green

Brown

Finish

Galvanized

Powder-coated

Material

Steel

Timber

Shape

Rectangle

Length

1914 mm

Width

1632 mm

3160 mm

4688 mm

6220 mm

7752 mm

Show more

Height

2084 mm

WarrantyDescription

Five year

Each metroSTOR® product comes with a five year replacement parts warranty.

Uniclass

Pr_20_65_78_15 Composite panelled sheltersPrimary

CAWS

B91/385 Shelter

B91/340 Cycle shelter

B91/355 Motorcycle shelter

B91/395 Storage unit

Q50/216 Scooter racks

Product range

Mobility Scooter Storage

Specification data - Composite panelled shelters

Shelter description

Mobility scooter storage and charging units.

Dimensions

-

Plan size

(Width x depth):

1632 x 1914 mm.

Height

2084 mm.

Cladding

Cladding panels finish and colour options:


(Insert requirements or colour code where necessary. Consult with manufacturer for samples.)

Firenze - Anthracite grey.

  • Pre-coated steel.
  • SSAB Greencoat Pural BT finish.

Firenze - Anthracite grey FR.

  • Pre-coated steel.
  • SSAB Greencoat Pural BT finish.
  • Non-combustible fire protection board liner.

Firenze - Nordic night black.

  • Pre-coated steel.
  • SSAB Greencoat Pural BT finish.

Firenze - Nordic night black FR.

  • Pre-coated steel.
  • SSAB Greencoat Pural BT finish.
  • Non-combustible fire protection board liner.

Firenze - Leaf green.

  • Pre-coated steel.
  • SSAB Greencoat Pural BT finish.

Firenze - Leaf green FR.

  • Pre-coated steel.
  • SSAB Greencoat Pural BT finish.
  • Non-combustible fire protection board liner.

Firenze - Walnut brown.

  • Pre-coated steel.
  • SSAB Greencoat Pural BT finish.

Firenze - Walnut brown FR.

  • Pre-coated steel.
  • SSAB Greencoat Pural BT finish.
  • Non-combustible fire protection board liner.

ForestPanel - SW TGV.

  • Sustainably sourced European redwood TGV plank.
  • Pressure treated preservative (green).

ForestPanel - TGV FR.

  • Sustainably sourced European redwood TGV plank.
  • Pressure treated preservative (green).
  • Non-combustible fire protection board liner.

Openings

-

Doors

Left hand hung.

Right hand hung.

Accessories

Not required.

External luminaires.

Charger shelf.

Storage

One class 1, 2 or 3 mobility scooter.

Locking

metroSTOR products are available with a range of robust locking options to suit the specific operational requirements. Manufactured in stainless steel with aluminium external handles and options for internal release.

Latch and code secure lock.

  • Code secured entrance.
  • Mechanical code lock.
  • 100% stainless steel mechanism and push buttons with aluminium handles.

Latch and euro-cylinder lock.

  • Self-latching daybolt.
  • Euro-cylinder key-operated self-latching bolt lock.
  • 100% stainless steel mechanism with aluminium handles.

Latch+RFID lock.

Functions

  • Durable rail-mounted system to rear of unit incorporates an IP rated electrical socket for connection of mobility scooter chargers. An optional charger shelf is available.
  • Efficient LED lighting with motion sensing PIR control for safe access and egress from scooter store at all times of day or night. External lighting can be added as an optional extra.
  • All PSM units are designed with space around the scooter for the connection of chargers and easy access.

Fire safety

  • Mobility scooters inside buildings can represent a serious fire risk. They are a potential source of ignition, they are highly combustible and if they are parked in hallways, they can be obstructing fire escapes. Many social landlords have banned scooters from being stored or charged inside residents’ flats or communal spaces to address fire risk assessment actions.
  • The National Fire Chiefs Council (NFCC) have developed statutory guidance to reduce fire risk associated with mobility scooter battery charging and storage. The recommendation is that if a fire-resistant storage area cannot be created within a building, then secure storage with provision for charging should be provided at least six metres from dwellings.
  • Installing metroSTOR PSM mobility scooter charging units provides a solution to address this guidance. To reduce fire risk if units cannot be located outside of the six metre recommended distance due to site constraints, metroSTOR PSM units can be specified with fire-resistant wall and roof cladding options, with intumescent seals incorporated into the eaves detail.


Environmental information

Country of product manufacture

United Kingdom

Recyclability

All non-production steel is 100% recycled and separated at source from fabrication and sheet metal processes. All timber cladding products are sustainably sourced and certified with non-production material separated at source for 100% recycling.
