Protan Vacuum System - Warm Roof Construction

Protan Vacuum System - Warm Roof Construction

Third party certifications:
  • BBA Agrément Certificate

    BBA Agrément Certificate

    Certificate type

Protan (UK) Ltd

PVC single-ply membrane roof system for warm roof constructions that requires no adhesives or fasteners - just the power of the wind.

Jump to:
+44 (0)1925 658001 www.protan.co.uk
Description

The Protan Vacuum System uses one-way air vents to suck the air out of the space between the Protan membrane and the substrate. This creates a vacuum within the space, which sucks the Protan membrane down to the substrate and holds it in place without the need for mechanical fixings or adhesives. The system is suitable for both new-build and refurbishment projects. The roof substrate and the membrane’s perimeter fasteners must be airtight. In order to assess the suitability of a particular building, it must be inspected and evaluated by a Protan Technical Services Manager.

Features:

  • Suitable for new-build and refurbishment applications on flat or pitched roofs.
  • Protan SE membrane is manufactured from pliable PVC reinforced with knitted polyester. The PVC contains stabilizers that provide fire resistance, make the product UV-stable and resistant to high and low temperatures. The membrane remains flexible at low temperatures, during installation and use.
  • Protan SE membrane has a unique anti-slip surface texture, which provides a significant safety factor when walked upon in wet weather.
  • Average cost savings of around 20% in comparison to an adhered system.

Durability:

  • Accelerated weathering tests and performance in service indicate that Protan SE membrane should have a life in excess of 40 years.
  • Protan SE 1.6/ 1.8 mm membranes may have an even longer life expectancy.
  • The use of lighter colours helps to reduce surface temperature and may thus improve the membrane's ageing performance.

Fire Resistance:

  • Results of tests indicate that a system comprising 0.7 mm profiled steel decking, 50 mm polyurethane insulation with an aluminium foil facing on the upper side and glass tissue facing to the underside, and one layer of Protan SE mechanically fixed, will be unrestricted.
  • Results of tests indicate that a system comprising 0.7 mm profiled steel decking, 0.21 mm thick Vapour Control Layer, 90 mm foil-faced polyurethane insulation, and one layer of Protan SE mechanically fixed can be classified under BS EN 13501-5:2005 as Broof (t4).
  • Results of tests indicate that a system comprising 0.7 mm profiled steel decking, a polyethylene Vapour Control Layer, 150 mm foil faced Kingspan TR26 PIR insulation and one layer of Protan SE mechanically fixed can be classified under BS EN 13501-5:2005 as Broof (t4).
  • Results of tests indicate that a system comprising an 18 mm plywood deck, a polyethylene Vapour Control Layer, 150 mm foil faced Kingspan TR26 PIR insulation and one layer of Protan SE mechanically fixed can be classified under BS EN 13501-5:2005 as Broof (t4).

Performance:

  • Tensile strength (EN12311-2): >1,050N / 50 mm.
  • Elongation at break (EN12311-2): >15%.
  • Tear strength (EN13210-2): 210N.

Substrates:

  • Concrete.
  • Other substrates will be assessed on a project-specific basis by Protan's Technical Services Department.

General information
Features

Suitable for new-build and refurbishment applications on flat or pitched roofs

Protan SE membrane is manufactured from pliable PVC reinforced with knitted polyester. The PVC contains stabilizers that provide fire resistance, make the product UV-stable and resistant to high and low temperatures. The membrane remains flexible at low temperatures, during installation and use

Protan SE membrane has a unique anti-slip surface texture, which provides a significant safety factor when walked upon in wet weather

Average cost savings of around 20% in comparison to an adhered system

Uniclass 2015
Ss_30_40_30_80 Single layer sheet warm roof covering systemsPrimary
CAWS

J42/10 Warm deck roof covering

J42/110 Warm deck roof covering

Specification data - Single layer sheet warm roof covering systems
Product Reference

Protan Vacuum System - Warm Roof Construction

Air Vapour Control Layer (VCL)

Protan ProFelt Torch-on Ali Air Vapour Control Layer

Type 5U glass-reinforced torch on bitumen felt

As manufacturer's instructions

Insulation

Rockwool

DuoRock/ HardRock

Tissue-Faced

Polyisocyanurate (PIR)

Spot bonded with 1 m² mineral wool underneath each Protan Vacuum Vent.

As manufacturer's instructions

Protan membrane -
Type

Protan SE Membrane

Protan EX-A Membrane

Thickness

1.2 mm

1.6 mm

1.8 mm

Only available with Protan SE Membrane.

Width

1000 mm

2000 mm

3960 mm

Only available with Protan SE Membrane.

As manufacturer's recommendations

Colour

Dark grey

Light grey

Accessories

None

Protan Air Sealing Tape

Protan Approved Fixings

Protan Approved Leaf Guard

Protan Approved Mastic

Protan Cover Strip

Protan G 1.5 mm Detailing Membrane

Protan Grip Bar

Protan Laminated Metal

Protan Lightning Conductor Clips

Protan Omega Profiles

Protan Prefabricated External Corners

Protan Prefabricated Internal Corners

Protan Prefabricated Pipe Collars

Protan ProJual Rainwater Outlets

Protan Stainless Steel Jubilee Clips

Protan Walkway Membranes

Protan Vacuum Vents

Standard product features

Roof deck:

Must be air-tight.

Vapour control layer:

Must be air-tight and load-bearing.

Components:

  • Protan air-sealing tape.
  • Protan fasteners.
  • Protan prefabricated details.
  • Protan grip bar.
  • Protan vacuum vents.

Product Options

Weight of waterproofing membrane:

- Protan SE Membrane:

  • 1.2 mm-thick: 1.4 kg/m².
  • 1.6 mm-thick: 1.8 kg/m².
  • 1.8 mm-thick: 2.0 kg/m².

– Protan EX-A 1.5 mm Membrane:

  • Thickness: 1.5 mm plus fleece.
  • Weight of membrane: 1.75 kg/m².
  • Weight of fleece: 180 g/m².
  • Roll width: 2 m.
  • Roll length: 20 m.
  • Unique anti-slip texture.

Accessories:

A wide range of accessories is available, including prefabricated components and Protan Laminated Metal for forming flashings and perimeter details.

Environment:

The system is fully recyclable; there is no contamination because no adhesives or solvents are used during installation. Additionally, the system can be thermally upgraded with ease, as fixings are only used around the perimeter and penetrations.

Durability:

Accelerated weathering tests and performance in service confirm that satisfactory retention of physical properties is achieved. All available evidence indicates that Protan SE membranes should have a life in excess of 30 years. Refer to BBA certificate No 98/3459.

Technical approval:

Further information about the Protan Vacuum roof system can be found in the NBI Technical Approval No 2281.

Maintenance and inspection:

In accordance with BS 6229, Protan recommends that the roof be inspected in spring and autumn for cleaning of gutters; ensuring outlets are clear and freeflowing and without evidence of damage. Special attention should be paid to the Protan Vacuum Vents.
