Application

Suitable for exposed Protan PVC single-ply membrane roof systems.

Description

Features:

  • Additional layers of Protan GT membranes can be used to create walkways for light or medium foot traffic across Protan PVC single-ply membrane roof systems.
  • The membranes can be used in conjunction with a galvanized steel spreader plate wrapped in Protan F2B Protection Fleece to prevent compression of the insulation. The spreader plate is secured on top of the insulation and beneath the Protan membrane.
  • For heavy foot traffic, Protan ProGrip R Walkway membrane is recommended.

Protan GT Membrane:

  • Thickness: 2.4 mm.
  • Weight: 2.5 kg/m².
  • Roll length: 10 m.
  • Roll widths: 2000 mm.
  • Tensile strength (EN 12311-2(A)): >500 N/50 mm.
  • Elongation at break (EN 12311-2(A)): >200%.
  • Tear strength (EN 13210-2): 130 N.
  • Unique slip resistant texture.
  • Designed for medium foot traffic.

Protan ProGrip R Walkway Membrane:

  • Thickness: 14 mm.
  • Width: 600 mm.
  • Roll length: 10 m.
  • Designed for heavy foot traffic and completely impervious to all weathers.
  • The cross directional top ribs combined with the ‘diamond cut’ top surface, gives excellent slip resistance, particularly when walking along the length of the walkway.
  • The walkway has been tested according to DIN 51130.

Application:

Suitable for exposed Protan PVC single-ply membrane roof systems.

General information
Finish

Unique anti-slip texture

Features

Additional layers of Protan GT membranes can be used to create walkways for light or medium foot traffic across Protan PVC single-ply membrane roof systems

The membranes can be used in conjunction with a galvanized steel spreader plate wrapped in Protan F2B Protection Fleece to prevent compression of the insulation. The spreader plate is secured on top of the insulation and beneath the Protan membrane

For heavy foot traffic, Protan ProGrip R Walkway membrane is recommended

Can be used in conjunction with a galvanized steel spreader plate wrapped in Protan F2B Protection Fleece to prevent compression of the insulation. The spreader plate is secured on top of the insulation and beneath the Protan membrane

Size

2.4 mm thickness, 10 m x 2000 m (roll l x w)

Uniclass 2015
Pr_25_57_51_51 Membrane walkwaysPrimary
Specification data - Membrane walkways
Product Reference

Protan GT Membrane Walkway

Protan ProGrip R Walkway Membrane

Reinforcement

Not required

Required

As manufacturer's recommendations

Width (minimum)

2000 mm

Minimum

2.4 mm

Colour

Black

Protan ProGrip R Walkway Membrane.

Dark Grey

Protan GT membranes.

Light Grey

Protan GT membranes.

Terrace Green

Protan GT membrane.

Standard product features

Features:

Can be used in conjunction with a galvanized steel spreader plate wrapped in Protan F2B Protection Fleece to prevent compression of the insulation. The spreader plate is secured on top of the insulation and beneath the Protan membrane.

Finish:

Unique anti-slip texture.

Size:

2.4 mm thickness, 10 m x 2000 m (roll l x w).
