Powder Coating - Interpon D2525 - Structura

Verified by manufacturer 2 months ago

Akzo Nobel Powder Coatings Ltd Product certifications:
  • EPD

    EPD

    Certificate type

A collection of popular RAL colours available in a tough structured texture finish.

Jump to:
BOS
+44 (0) 845 6032401 Website

Application

Intended for use on architectural aluminium and galvanized steel.

Description

A collection of RAL colours in a tough, scratch-resistant textured finish, Structura provides a robust coating proven to limit visible blemishes on the surface.


Features and benefits:

  • Super durable polyester.
  • Offers a robust textured finish.
  • For areas of high traffic volume.
  • Minimum guarantee of 30 years by approved applicators.

General information

Color

Other

Guidance for specification option:

Please refer to Structura colour card for available colours.

Finish

Textured

Guidance for specification option:

Fine texture.

Material

Polyester

Warranty description

40 year

Guidance for specification option:

 (UK application only).

Uniclass

Pr_35_31_68_66 Powder coatingsPrimary

CAWS

H92/120 Rainscreen cladding

L10/400 Composite windows

L10/330 Aluminium windows

H43/120 Metal insulating sandwich panel

R10/395 Continuously hot dip coated steel pipework - pressed

R10/370 Aluminium pipework

R10/335 Galvanized steel gutters

R10/311 Aluminium gutters

L35/420 Carbon steel components

L35/410 Aluminium components

H31/120 Metal

H31/110 Metal

H13/115 Structural glass assembly

H11/145 Integrated access equipment

H11/140 Louvres

H11/135 Doors

H11/130 Sun screens

H11/110 Curtain walling

R10/30 Aluminium pipework

R10/11 Aluminium gutters

H10/115 Patent glazing

L10/45 Rooflights

L10/33 Proprietary windows

L10/20 Steel windows

H10/10 Patent glazing

L20/370 Door frames

L20/280 Doors

L10/25 Aluminium windows

Z31/120 Powder-coating materials

L10/460 Rooflights

L10/550 Glazed metal screens

L20/480 Doorsets

H92/130 Major non-standard components

L10/310 Steel windows

L10/650 Metal louvres

Specification data - Powder coatings

Classification data

Standard

To aluminium: BS EN 12206-1/Qualicoat.
To galvanized steel: BS EN 13438.

Powder formulation

Polyester TGIC free.

Guidance for specification option:

Super durable.

Colour

YD313F 1013.
YD315F 1015.
YD319F 1019.
YG300F 3000.
YG304F 3004.
YG305F 3005.
YQ302F 5002.
YJ303F 5003.
YQ305F 5005.
YJ362F 5007.
YJ375F 5008.
YJ309F 5009.
YJ310F 5010.
YJ352F 5014.
YJ315F 5015.
YJ317F 5017.
YJ323F 5023.
YJ324F 5024.
YK303F 6003.
YK305F 6005.
YK309F 6009
YK317F 6017.
YS319F 6019.
YK321F 6021.
YK356F 6025.
YK327F 6027.
YK329F 6029.
YL300F 7000.
YP301F 7001.
YL304F 7004.
YL305F 7005.
YL306F 7006.
YL310F 7010.
YP311F 7011.
YL312F 7012.
YL315F 7015.
YL316F 7016.
YL321F 7021.
YL322F 7022.
YL323F 7023.
YL324F 7024.
YP330F 7030.
YL374F 7031.
YL334F 7034.
YL335F 7035.
YL357F 7036.
YL337F 7037.
YP338F 7038.
YL339F 7039.
YL340F 7040.
YL342F 7042.
YP343F 7043.
YP344F 7044.
YL347F 7047.
YM362F 8003.
YM311F 8011.
YM314F 8014.
YM316F 8016.
YM352F 8017.
YM319F 8019.
YM325F 8025.
YM363F 8028.
YU301F 9001.
YU302F 9002.
YB303F 9003.
YN304F 9004.
YN305F 9005.
Y2328F 9006.
Y2329F 9007.
YA310F 9010.
YN311F 9011.
YA316F 9016.
YN358F 9017.
YL318F 9018.

Accelerated weathering

Gloss retention >50% (QUV B 313, 300 hours).
>90% (BS EN ISO 11341, 1000 hours).

Guidance for specification option:

Marine environment.

Acetic acid salt spray resistance

<16 mm² corrosion/10cm.

Guidance for specification option:

(1000 hours).

Adhesion

Gt0 (2 mm crosshatch).

Chemical resistance

Generally good resistance to acid, alkalis and oil at normal temperatures.
Not applicable.

Colour stability at elevated temperatures

Excellent.
Not applicable.

Coverage

4–6 m².
Not applicable.

Dry film thickness

60 µm.

Fire classification (EN 13501-1)

A2-s1, d0.

Flexibility

Pass Qualicoat Class 2 requirements.
Not applicable.

Florida exposure

Compliant with Qualicoat Class 2/GSB Master requirements after 3 years Florida and AAMA 2604 requirements after 5 years Florida.

Gloss level

3–7 gloss units.

Impact resistance

Qualicoat Class 2 requirements.
Not applicable.

Mortar resistance

No effect after 24 hours.
Not applicable.

Permeability resistance

Pressure cooker - pass, 1 hour no defects.
Not applicable.

Sustainability data

Material

Polyester

A1-A3 (production stage)

Normalised unit

3.7 kg CO₂ eq/kg

Declared unit

3.70 kg CO₂ eq/kg

Certified

Lower emissions

Product certifications

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit

Revit 2016

6

IFC

IFC2X3

5

Product certifications

EPD

EPD

EPD: Interpon D Architectural Series- Interpon D2000 (D2525/D2015)

Literature

Interpon D2525 Structura

Interpon D2525 Structura
