Powder Coating - Interpon D1036 RAL - Metallic
Verified by manufacturer 7 months ago
QA Certificate
Certificate type
Subtle metallic powder coating formulated in standard durability.
Application
For aluminium and galvanized steel.
Description
Subtle metallic powder coating formulated in standard durability.
Features and benefits:
- AkzoNobel's offer for the RAL pearlescent standards.
- Provide an alternative to solid RAL shades.
- Durable.
General information
Finish | Metallic |
Material | Polyester |
WarrantyDescription | 30 year (UK application only). |
Uniclass | |
CAWS | H10/10 Patent glazing H10/115 Patent glazing H11/110 Curtain walling H11/130 Sun screens H11/135 Doors H11/140 Louvres H11/145 Integrated access equipment H13/115 Structural glass assembly H31/110 Metal H31/120 Metal H43/120 Metal insulating sandwich panel H92/120 Rainscreen cladding H92/130 Major non-standard components L10/20 Steel windows L10/25 Aluminium windows L10/310 Steel windows L10/315 Steel windows L10/33 Proprietary windows L10/330 Aluminium windows L10/335 Aluminium windows L10/400 Composite windows L10/45 Rooflights L10/460 Rooflights L10/550 Glazed metal screens L10/56 Glazed screen system L10/650 Metal louvres L20/280 Doors L20/370 Door frames L20/480 Doorsets L35/410 Aluminium components L35/420 Carbon steel components R10/11 Aluminium gutters R10/30 Aluminium pipework R10/311 Aluminium gutters R10/335 Galvanized steel gutters R10/370 Aluminium pipework R10/395 Continuously hot dip coated steel pipework - pressed Z31/120 Powder coating materials |
Specification data - Powder coatings
Standard | To aluminium: BS EN 12206-1/Qualicoat.To galvanized steel: BS EN 13438. |
Powder formulation | Polyester TGIC free. |
Colour | SW240F 1035. SW241F 1036. SW242F 2013. SW247F 5025. SW248F 5026. |
Accelerated weathering | Gloss retention: >50% (BS EN ISO 11341, 1000 hours). |
Acetic acid salt spray resistance | <16 mm² corrosion/10 cm. (1000 hours). |
Adhesion | Gt0 (2 mm crosshatch). |
Chemical resistance | Generally good resistance to acid, alkalis and oil at normal temperatures. |
Colour stability at elevated temperatures | Good. |
Coverage | 3.5–4 m². |
Dry film thickness | 60 microns. |
Fire classification (EN 13501-1) | A2,s1-d0. |
Flexibility | 5 mm. |
Florida exposure | Compliant with Qualicoat Class 1/GSB/AAMA 2603 requirements after 1 year Florida. |
Gloss level | 25–35 gloss units. |
Impact resistance | 2.5 Joules reverse and direct. (20 in lb). |
Mortar resistance | No effect after 24 hours. |
Permeability resistance | Pressure cooker - pass, 1 hour no defects. |
Environmental information
Embodied carbonA1-A3 (production stage) as defined in BS EN 15804 | 3.29 kg CO₂ eq/kg |
Third party certifications
- Qualicoat: Certificate: Class 1
- GSB: Class
- AAMA: Certificate: AAM 2603
Literature
Lighting Up The Shard: Interpon D2525 Superdurable Polyester Powder Coating
