Verified by manufacturer 7 months ago
QA Certificate
Certificate type
Subtle metallic powder coating formulated in standard durability.
For aluminium and galvanized steel.
Subtle metallic powder coating formulated in standard durability.
Features and benefits:
Finish | Metallic |
Material | Polyester |
WarrantyDescription | 30 year (UK application only). |
Uniclass | |
CAWS | H10/10 Patent glazing H10/115 Patent glazing H11/110 Curtain walling H11/130 Sun screens H11/135 Doors H11/140 Louvres H11/145 Integrated access equipment H13/115 Structural glass assembly H31/110 Metal H31/120 Metal H43/120 Metal insulating sandwich panel H92/120 Rainscreen cladding H92/130 Major non-standard components L10/20 Steel windows L10/25 Aluminium windows L10/310 Steel windows L10/315 Steel windows L10/33 Proprietary windows L10/330 Aluminium windows L10/335 Aluminium windows L10/400 Composite windows L10/45 Rooflights L10/460 Rooflights L10/550 Glazed metal screens L10/56 Glazed screen system L10/650 Metal louvres L20/280 Doors L20/370 Door frames L20/480 Doorsets L35/410 Aluminium components L35/420 Carbon steel components R10/11 Aluminium gutters R10/30 Aluminium pipework R10/311 Aluminium gutters R10/335 Galvanized steel gutters R10/370 Aluminium pipework R10/395 Continuously hot dip coated steel pipework - pressed Z31/120 Powder coating materials |
Standard | To aluminium: BS EN 12206-1/Qualicoat.To galvanized steel: BS EN 13438. |
Powder formulation | Polyester TGIC free. |
Colour | SW240F 1035. SW241F 1036. SW242F 2013. SW247F 5025. SW248F 5026. |
Accelerated weathering | Gloss retention: >50% (BS EN ISO 11341, 1000 hours). |
Acetic acid salt spray resistance | <16 mm² corrosion/10 cm. (1000 hours). |
Adhesion | Gt0 (2 mm crosshatch). |
Chemical resistance | Generally good resistance to acid, alkalis and oil at normal temperatures. |
Colour stability at elevated temperatures | Good. |
Coverage | 3.5–4 m². |
Dry film thickness | 60 microns. |
Fire classification (EN 13501-1) | A2,s1-d0. |
Flexibility | 5 mm. |
Florida exposure | Compliant with Qualicoat Class 1/GSB/AAMA 2603 requirements after 1 year Florida. |
Gloss level | 25–35 gloss units. |
Impact resistance | 2.5 Joules reverse and direct. (20 in lb). |
Mortar resistance | No effect after 24 hours. |
Permeability resistance | Pressure cooker - pass, 1 hour no defects. |
Embodied carbonA1-A3 (production stage) as defined in BS EN 15804 | 3.29 kg CO₂ eq/kg |
