PLANITHERM® ULTRA N/N II
Verified by manufacturer 9 days ago
Low-emissivity glass that provides advanced thermal insulation
Application
PLANITHERM® ULTRA N/N II offers superior thermal insulation properties in combination with high neutrality. It is positioned specifically for commercial exterior applications but is also suitable for domestic applications:
COMMERCIAL SOLUTIONS
- Façades and windows
- Structural glazing
- Overhead glazing
RESIDENTIAL SOLUTIONS
- Windows and skylights
- Patio doors, French doors
- Other external doors
- Conservatories and sunrooms
For further information, visit our website - click here
Description
PLANITHERM® ULTRA N/N II THERMAL GLASS
PLANITHERM® ULTRA N/N II is a high-performance, thermally insulating Low-Emissivity (Low-E) glass that offers very good thermal insulation coupled with supreme neutrality, and is positioned ideally for commercial applications. Manufactured in Britain, PLANITHERM® ULTRA N/N II can be toughened and is available in a range of thicknesses, providing versatility for various project requirements. Its key benefits include:
- Excellent thermal insulation performance, helping to reduce heating bills and eliminate cold areas around windows.
- Neutral aesthetics that maximise the transmission of natural light into the building.
General information
Color | Clear |
Finish | Coated Guidance for specification option: low-emissivity (e) coating. |
Material | Glass |
Shape | Rectangle |
Length | 6000 mm |
Width | 3210 mm |
Uniclass | |
CAWS | H10/10 Patent glazing H13/115 Structural glass assembly H10/115 Patent glazing H11/110 Curtain walling |
Specification data - Annealed glass sheets
Third-party certification | CE Marked, Environmental Performance Declaration (EPD), Building Regulation (E&W) Approved Document L compliant |
Thickness | 4 mm6 mm6.8 mm7.5 mm8 mm8.8 mm10 mm10.8 mm |
Body colour | Clear |
Coating | |
Type | Low-emissivity. |
Performance requirements | |
Light | Light Transmission: 80% (with PLANICLEAR® 6/16(Ar)/4 doubled glazed unit) |
Solar control | Solar Factor: 0.64 (with PLANICLEAR® 6/16(Ar)/4 doubled glazed unit) |
Substrate glass | PLANICLEAR® Guidance for specification option: Standard. STADIP® STADIP PROTECT® |
Processing | Guidance for specification option: Consult manufacturer and insert requirements. |
Standard | BS EN 1096: Class B |
Panel size | 3210 x 6000 mm Special order |
Sustainability data
Country of product manufacture | United Kingdom |
Recyclability | Saint-Gobain Glass products are manufactured using a minimum of 30% recycled content. |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 30 % |
Literature
SGG PLANITHERM ULTRA N / ULTRA N II
