Plafotherm® E 200


Zinc-galvanized metal heating and cooling ceiling panels with powder coated surfaces on visible side, hung in a concealed substructure. Manufactured in accordance with European standards and the technical regulation of TAIM e.V.

System comprises:

  • Metal ceiling panel.
  • Heating and cooling technology: Consisting of heat conducting element and Cu-pipe or V2A-pipe frets thermally conductive integrated into ceiling panel.
  • Vernier suspension: Manufactured from zinc-galvanized steel, consisting of hanger upper section, hanger lower section, and safety split pins which are variably adjustable for suspension of suspension channel grid.
  • Hook-on profile: Manufactured from zinc-galvanized steel to support metal ceiling top layer.
  • Suspension channel: Manufactured from zinc-galvanized steel, as substructure for supporting profiles.

General information


Electrostatically applied powder coating

Uniclass 2015

Ss_30_25_22_90 Unit/ modular suspended ceiling systemsPrimary


K40/10 Unit/ modular suspended ceilings

K40/115 Unit/ modular suspended ceiling system

Specification data - Unit/ modular suspended ceiling systems

Product Reference

E 200 Heat conducting profile with Cu-pipe

E 200 Heat conducting profile with V2A-pipe

E 200 Activation board with Cu-pipe

Ceiling type

Hook-on/ Lay-on

Hook-on both sides



Panel size

Length up to 2950 mm, width up to 1250 mm, manufactured from 0.7 mm zinc-galvanized steel, insert requirements.




Rv 1,8–20

Rg 2,5–16

Rv 3,0–20


RAL 9010

Manufacturer's standard.


Insert requirements.


Insert requirements.

Wall connection


30 x 30 mm, L-angle aluminium

25 x 20 x 20 x 35 mm, corresponding angle, aluminium

Standard product features

Fire performance (BS EN 13501):

  • Panels: A2-s2, d0 (non-combustible).
  • Substructure: A1.




Electrostatically applied powder coating.

Sound absorption:

Dependent on level of perforation and acoustic inlay. Consult manufacturer.

Connecting/ connection hose:

Made of pressure stable, flexible hose which is steel covered and oxygen diffusion-proofed according to DIN 4726 with removable plug system for the connection of the individual heated and chilled ceiling panels.

Hydraulic connection:

The individual heated and chilled ceilings are connected in series (heating and cooling zones) until a pressure loss of approximately 25–30 kPa is achieved. The individual heating and cooling zones are connected parallel to the distribution pipe (regulation zone).

Product Options

Product reference:

- Activation board with Cu-pipe:

15 mm graphite panel, size depending on ceiling panel. Cu-pipe calibrated and shaped as a fret. Various axial distances possible.

- Heat conducting profile with Cu-pipe:

Aluminium extruded section in standard widths of 80 or 120 mm. V2A-pipe calibrated and shaped as a fret with pressed in hollow shafts by machine. Various axial distances from 45 mm are possible.

- Heat conducting profile with V2A-pipe:

Aluminium extruded section in standard widths of 80 or 120 mm. V2A-pipe calibrated and shaped as a fret. Various axial distances from 45 mm are possible.


Three standard perforations available. Other perforations available on request. Consult manufacturer for perforation patterns.

C-post cap:

Other sizes are available, consult manufacturer.

Heating and cooling capacities:

Consult manufacturer for details.
