Pilkington K Glass™ S Low Emissivity
Verified by manufacturer 4 days ago
ISO 9001 Quality Management
Certificate type
EPD
Certificate type
Clear low emissivity soft coated thermally insulating glass.
Application
Suitable for fabrication into an IGU, where it can be used in windows in all types of glazing applications for new houses, conservatories and in replacement windows for existing homes.
Description
Pilkington K Glass™ S is our latest high performance, low-emissivity soft coated product which offers excellent thermal insulation when incorporated within an Insulating Glass Unit (IGU).
It has a highly neutral appearance with optimal solar heat gain, thermal insulation and light transmission to provide the highest Window Energy Rating (WER) performance.
Pilkington K Glass™ S is a single stock, soft coated glass which can be used in annealed form or toughened, resulting in a product with the same thermal performance and neutral appearance. Once fabricated into an IGU, it can be used in windows in all types of glazing applications in new houses, conservatories and in replacement windows for existing homes.
Benefits
- An alternative to the original hard coated Pilkington K Glass™
- When incorporated into a Pilkington energiKare™ double glazed unit, it can easily achieve up to and beyond A++ rated windows in all frame materials
- Helps windows exceed Building Regulations concerning energy efficiency in homes now and for the future changes expected
- Enables householders to reduce energy usage and save money on heating bills
- Environmentally friendly helping to achieve the Government’s targets for reducing CO2 emissions from homes
- Helps to reduce drafts near windows to create a more useful space in rooms
- Excellent light transmission which helps to reduce the need for artificial lighting
- Suitable for use in PVC-U, timber and aluminium profiles in both new and replacement windows
- Available in annealed form and can be toughened or laminated for use in areas which require safety glazing
- Edge-deletion is not required when using Pilkington approved secondary sealants in an IGU.
General information
Color | Clear |
Finish | Coated |
Material | Glass |
Shape | Rectangle Square |
Length | Bespoke Guidance for specification option: Maximum. |
Width | Bespoke Guidance for specification option: Maximum. |
Height | 4 mm 6 mm |
Warranty description | Manufacturer guidanceDependant on unit supplier |
Uniclass | |
CAWS | L40/371 Bead-fixed insulating glass units – cellular adhesive/ mastic tape L40/380 Bead-fixed insulating glass units – solid bedding, outside bead L20/430 Wood doorsets L20/420 Wood doorsets L40/370 Bead-fixed insulating glass units – insert gasket sections L40/381 Bead-fixed insulating glass units – solid bedding, inside bead L40/450 Single glazing into grooves – sealant capping L40/410 Single glazing into grooves – extruded rubber/ PVC sections L40/372 Bead-fixed insulating glass units – loadbearing tapes/ synthetic rubber and sealant capping L40/250 Bead-fixed single glazing – tape and sealant L40/55 Bead-fixed insulating glass units – drained and ventilated bead L20/480 Doorsets L20/25 Wood panelled doors L10/45 Rooflights L10/33 Proprietary windows L10/31 PVC-U windows L10/30 PVC-U windows L10/25 Aluminium windows L10/20 Steel windows L10/15 Wood windows L10/10 Wood windows L40/350 Bead-fixed single glazing – curing compound and trim L40/230 Bead-fixed single glazing – non-setting compound L20/410 Wood doorsets L40/470 Zipper gasket glazing L20/250 Wood panelled doors L40/490 Single-sided gasket glazing H10/10 Patent glazing L40/430 Single glazing into grooves – non-setting compound L20/20 Wood flush doors L40/57 Bead-fixed insulating glass units – solid bedding, outside bead H10/115 Patent glazing L40/310 Bead-fixed single glazing – tape, sealant and trim L20/280 Doors L40/260 Bead-fixed single glazing – extruded gasket L40/58 Bead-fixed insulating glass units – solid bedding, inside bead L40/330 Bead-fixed single glazing – capping L10/580 Secondary glazing system L10/560 Glazed screen system L10/550 Glazed metal screens L10/510 Glazed wood screens L10/480 Roof windows L10/460 Rooflights L10/400 Composite windows L10/390 Proprietary windows L10/350 PVC-U windows L10/330 Aluminium windows L10/310 Steel windows L10/210 Wood windows L20/230 Wood flush doors L20/55 Doorsets H13/115 Structural glass assembly H11/110 Curtain walling L40/50 Bead-fixed single glazing |
Specification data - Annealed glass sheets
Thickness | 4 mm.6 mm. |
Body colour | Clear. |
Coating | |
Type | Low-emissivity, soft coat, thermal insulating. |
Size: | 6000 x 3210 mm (maximum). |
Sustainability data
Contains Red List materials | No |
Country of material origin | Europe |
Country of product manufacture | United Kingdom |
Material | Glass |
Embodied carbonA1-A3 (production stage) as defined in BS EN 15804 | 2.79 kg CO₂ eq/m² |
Recyclability | The products can be re-melted in float lines following correct separation. |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 20 % Guidance for specification option: Estimate batch percentage |
Third party certifications
Pilkington Offline Coated Float Glass EPD Pilkington Thermally Toughened Offline Coated Float Glass EPD Pilkington Double IGU (4/16/4) with Offline coated glass EPD Pilkington Double IGU (6/16/6) with Offline Coated Glass EPD Pilkington Double IGU (4/16/6.8) with Offline Coated Laminated Glass EPD Pilkington Double IGU (8.8/16/6) with Offline Coated Laminated Glass EPD Pilkington Double IGU (6/16/8.8) with Toughened Offline Coated Glass EPD Pilkington Triple IGU (4/12/4/12/4) with 2 x Offline Coated Glass EPD Pilkington Triple IGU (6/12/6/12/8.8) with 2 x Offline Coated Glass EPD
Third party certifications
ISO 9001 Quality Management
ISO 9001:2015 - Quality Management System
EPD
Pilkington Offline Coated Float Glass EPD
EPD
Pilkington Thermally Toughened Offline Coated Float Glass EPD
EPD
Pilkington Double IGU (4/16/4) with Offline coated glass EPD
EPD
Pilkington Double IGU (6/16/6) with Offline Coated Glass EPD
EPD
Pilkington Double IGU (4/16/6.8) with Offline Coated Laminated Glass EPD
EPD
Pilkington Double IGU (8.8/16/6) with Offline Coated Laminated Glass EPD
EPD
Pilkington Double IGU (6/16/8.8) with Toughened Offline Coated Glass EPD
EPD
Pilkington Triple IGU (4/12/4/12/4) with 2 x Offline Coated Glass EPD
EPD
Pilkington Triple IGU (6/12/6/12/8.8) with 2 x Offline Coated Glass EPD
Literature
Pilkington K Glass™ Range Brochure
Pilkington UK Glass Range Brochure
Pilkington UK Glass Range Datasheet
