PHS (Penetrating Hardening System)
Verified by manufacturer over a year ago
A two-component, solvent-free, epoxy resin to reinforce failed cement/ sand screeds.
Application
Suitable for use where work needs to be completed to a tight deadline in refurbishment programmes.
IMPORTANT: All specification information must be checked against the individual site requirements. Flowcrete advises that specifications are confirmed with their technical experts.
Description
A low viscosity, solvent-free liquid used to refurbish and re-strengthen failed cement/ sand screeds by penetrating PHS into the defective screed, filling voids and bonding material together to provide a high strength floor screed.
Features and benefits:
- Fast cure.
- BRE test category A.
- BS 8204 -1.
- High speed installation.
- Impermeable to water.
General information
Finish | Gloss |
Material | Resin |
Warranty description | Ten year |
Uniclass | |
CAWS | M40/20 Existing backgrounds/ bases generally M40/320 Existing concrete/ screeds M50/460 Smoothing/ levelling underlayment compound M50/65 Laying coverings |
Specification data - Epoxy mortars
Abrasion resistance | AR1/DF: Very heavy duty. |
Bond strength | 2.2 N/mm². |
BRE test | Category A. |
CompressiveStrength | >70 N/mm². |
Concrete replacement material | Two-component epoxy. |
Corrosion prevention coating to reinforcement | Commercial: Isocrete 1500, Industrial: Flowshield SL. |
Cure time | Light traffic: 8 hours, Full cure time: 12 hours. |
Flexural strength | >70 N/mm². |
Freeze thaw cycle | No loss of adhesion. |
TensileStrength | 60 N/mm². |
Uses | Re-strength and refurbish failed cement/ sand screeds. |
Vapour Permeability | 2 gms/m²/24hrs. |
Water permeability | Guidance for specification option: w<0.01 kg/m²="" x="">. |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 IFC | - | 2 |
 Revit | - | 3 |
