Permanently fixed vertical ladder system - aluminium ladders

Name: Permanently fixed vertical ladder system - aluminium ladders
Brand: Safety Fabrications Limited
SKU: htqaz9qJWJoX1bBcmQqktR

Verified by manufacturer 4 months ago

Safety Fabrications Limited

Third party certifications:

TUV - Safety and Quality Report
Certificate type

Aluminium fixed vertical ladders are designed to provide safe access for heights between 2 - 10m in a single flight all in accordance with BS EN ISO 14122-4. (larger sizes are available).

Jump to:

BOS

+44 (0)1142852203 Website

Application

Ascent Fixed Access ladders provide simple access solutions to complex access issues, including how to gain safe access to a rooftop or item of plant such as a Silo or tank without compromising the health and safety of the worker.

Description

A Permanently-fixed vertical ladder system made form aluminium designed to provide safe access for heights between 2 - 10m in a single flight all in accordance with BS 4211. (larger sizes are available). The Ascent ladders can be supplied with / without safety cage and guardrail. The Ascent ladders can be supplied to create access both externally onto a roof and internally to a roof hatch. All Ascent ladders are manufactured in accordance with CE / UKAS factory construction control procedures.

Fixed, vertical ladders that provide a simple access solution to roof or raised flooring height for maintenance and other occasional use. Investment in design and manufacturing technology has allowed for an access ladder system designed in accordance with BS EN ISO 14122-4 and manufactured in accordance with BS EN ISO 3834-2 and BS EN 1090-1 + A1. This has produced an accurately manufactured product which is both easy to specify and install. An off the shelf product which will meet the challenges faced when creating safe access at height.

Features and benefits:

The range offers on-site adjustment to meet all needs whilst giving the safety and finished appearance of a bespoke product.
Available with either a simple step through at the head or a platform to clear obstructions with the option of a step down to suit. A separate fall protection system in accordance with EN 353-1 can be fitted, or hoops can be supplied from stock where required.
Supplied with either a bracketry fixing kit or with freestanding feet where floor/ roof penetration is not possible.
All Ascent™ products have been approved through the necessary safety and structural calculations and are supplied in compliance with BS EN ISO 3834-2 and BS EN 1090-1 and are CE marked.
General arrangement drawings provided.
Supplied flat pack with easy to follow installer instructions.
Assembly fixings supplied, fixings to structure not included.
Design incorporates on-site levelling adjustment.
Standards range of heights up to 10 m.
Standard platform lengths up to 1500 mm.
Aluminium ladders are 60% lighter than their mild steel galvanised equivalent. Making for an easier installation.

General information

Color	Grey Other
Finish	Mill
Material	Aluminium
Length	Bespoke Guidance for specification option: Maximum standard platform length.
Width	400 mm
Height	10000 mm Guidance for specification option: Maximum standard range for heights.
Warranty description	20 year Manufacturer guidance Manufacturer advice to be sought on warranty conditions

Uniclass	Ss_35_10_30_62 Permanently-fixed vertical ladder systemsPrimary
CAWS	L30/410 Steel ladders L35/130 Ladder system L35/330 Ladders

Specification data - Permanently-fixed vertical ladder systems

System accessories	None. Anti-climb hoop cover. Anti-climb ladder guard. Ladder up post. Self-closing gate.

Base fixing	Freestanding feet. Guidance for specification option: Where roof/ floor penetration is not possible. To concrete. Guidance for specification option: Where roof/ floor penetration is possible (bracketry fixing kit).
Safety	Not required. Fall protection system. Hoops.
Width	400 mm.
Standards	To BS EN ISO 3834-2 and BS EN 1090-1 + A1 and 2.
Third-party certification	CE marked.

Sustainability data

Contains Red List materials	No
Country of material origin	United Kingdom
Country of product manufacture	United Kingdom
Material	Aluminium
Embodied carbon A1-A3 (production stage) as defined in BS EN 15804	8.3 kg CO₂ eq/kg Self declared
Recyclability	85
Recycled content As defined in clause 7.8 of BS EN ISO 14021	30 %
