Application

Indoors or outdoors, including coastal areas.

Description

Vertical Long Travel range of platform lift for travel up to up to 3m


Features and benefits.


  • Self-supporting structure,
  • Can be installed indoors or outdoors, including coastal areas

General information
Color

Grey

Stainless Steel as standard

RAL colours available

Features

Self-supporting structure, can be installed indoors or outdoors, including coastal areas

Finish

Powder coated

Material

Steel

316 Stainless Steel

Shape

Rectangle

Size

720 x 1000 mm

660 mm clear opening

1100 x 1400 mm

900 mm clear opening

1200 x 1400 mm

900 mm clear opening

800 x 1400 mm

800 mm clear opening

Uniclass 2015
Pr_65_80_47_95 Vertical lifting platformsPrimary
Specification data - Vertical lifting platforms Enhanced data
Standard

EN 81-41

Rated load (minimum)

320 kg

720 x 1000 mm and 1100 x 1400 mm platform

385kg

1200 x 1400 mm and 800 x 1400 mm platform

Drive type

Screw and nut.

Carriage type

Full-height.

Gate

Carrier -
Frame material

Steel

316 Stainless Steel

Frame finish

Powder-coated.

Frame colour

Grey as standard but other colours available

Infill material

Glass

Solid Steel Panel

Doors -
Arrangement

Single.

Through.

Adjacent.

Type

Full glass, hinged.

Steel hinged

Frame material

Steel

316 Stainless steel

Frame finish

Powder-coated.

Infill material

Laminated glass.

Opaque glass

Stopsol glass

Steel

Infill finish

Powder-coated.

Carrier floor -
Dimensions -
Width (minimum)

1120 mm

Depth (minimum)

1070 mm

Control device type

One push button

Control features

Hold to run

Environmental information
Country of material origin

France

Country of product manufacture

France
