Paraline Powder Coat Panel Cubicle

Verified by manufacturer 5 months ago

HPL

Bushboard Washroom Systems Ltd Variant:

A contemporary and streamlined washroom cubicle with slimline aluminium pilasters.

Jump to:
+44 (0)1536 533620 Website

Application

Suitable for contemporary settings with minimalist style.

Description

A modern panel cubicle with powder coated fittings ensuring an ultra durable and stylish washroom.


Features and benefits:

  • slender aluminium pilasters that are connected and reinforced by a single aluminium headrail to deliver minimalist style.
  • Durable ABS lock and powder coated aluminium legs.
  • Can be specified with Stainless steel cubicle hardware.


Components:

  • HPL: High pressure laminate panels, supplied square edged with matching 1 mm PVC lipping.
  • MFC: Melamine faced panels, supplied square edged with matching 1 mm PVC lipping.
  • SGL: Solid grade laminate panels, supplied with polished black radiused edges.
  • Frame comprising: Headrail, pilaster, legs, hinges and channel.

General information

Color

Brown

Grey

Manufacturer guidance

Panels: 34 laminate colour options and a selection of wood veneers; select from manufacturer literature.

Finish

Smooth

Laminated

Guidance for specification option:

Panels.

Powder-coated

Guidance for specification option:

Aluminium frame components.

Material

Laminate

Guidance for specification option:

Panels.

Chipboard

Guidance for specification option:

Backing, moisture resistant.

Aluminium

Guidance for specification option:

Frame components.

Shape

Rectangle

Uniclass

Ss_25_12_60_60 Panel cubicle systemsPrimary

CAWS

K32/10 Panel cubicles

K32/120 Panel cubicles

Product range

Cubicles

Specification data - Panel cubicle systems

Panels

HPL facings, 680 kg/mÂł grade chipboard backing, square edged.

Guidance for specification option:

  • HPL: High pressure laminate.
  • Moisture resistant chipboard.

Panel supports

Aluminium frame.

Pilasters

Aluminium.

Doors

HPL facings, 680 kg/mÂł grade chipboard backing, square edged.

Guidance for specification option:

  • HPL: High pressure laminate.
  • Moisture resistant chipboard.

Lippings

1 mm PVC lipping.

Guidance for specification option:

Supplied.

Hardware

Headrail, pilaster, legs, hinges and channel.

System accessories

Not required.

Soap dispensers.

Paper towel dispensers.

Toilet roll holders.

Hand dryers.

Coat hooks.

Door handles.

Manufacturer guidance

Selection available, consult manufacturer literature.

Height (Refer to manufacturer's guidance)

Guidance for specification option:

Insert panel height requirement.

  • Maximum height: 2020 mm (including floor clearance).
  • Full height: Up to 2770 mm.
  • Bespoke height: minimum 150 mm.
  • Floor to ceiling: 30 mm.

Manufacturer guidance

  • Full height: refers to any height between the standard 2020 mm and ceiling height; this requires a minimum of 20 mm ceiling clearance.
  • Floor to ceiling: refers to anything above standard height which is fixed directly to the ceiling with a total of 20 mm ceiling clearance; Paraline at this height should be specified without a headrail.

Other requirements

Not required.

Stylex printed doors.

Wood veneer doors.

Pilasters & Headrail

Light grey, powder coated aluminium.

Manufacturer guidance

Colour.

Faceplate

Stainless steel.

Light grey.

Manufacturer guidance

Colour.

Hinges & Channels

Light grey.

Manufacturer guidance

Colour.

Pedestal Foot

20 mm Stainless steel.

100 mm Stainless steel.

105 mm Titanium powder-coat with plastic shroud.

105 mm Mineral powder-coat with plastic shroud.

105 mm Lines.

Show more

Manufacturer guidance

Colour.

Panels

-

Manufacturer guidance

Colour panels: 34 laminate colour options and a selection of wood veneers; select from manufacturer literature.

Overall thickness

19 mm (nominal).
