Compare

PanelHush Fabric Wall Panels

Name: PanelHush Fabric Wall Panels
Brand: ModernGlide Ltd
SKU: 2UrCMe87DiZdGGBhfb8g9H

Verified by manufacturer 22 days ago

ModernGlide Ltd

Wall-mounted, acoustic sound absorption panels.

Jump to:

Request BIM

+44 (0)1932 918338 Website

Application

Suitable for a variety of settings from small office environments to auditorium spaces.
Solution for community halls, education and healthcare settings, offices, leisure, retail and entertainment spaces where echo reverberation is an issue.

Description

PanelHush Acoustic Sound Absorption Panels are designed and manufactured to offer up to Class A sound absorption.

Features and benefits:

Easily installed.
Suitable for a range of environments.
Up to CLASS A sound absorption.
Short lead times.
UK factory.
Customized sizes, shapes and finishes.
Supply only and installation options.
25 mm Class C and 40 mm Class A panels.

General information

Color	Yellow Red Orange Blue Green Ivory Grey Purple White Black Beige Cream Pink Gold Silver Turquoise Brown Other Copper Bronze Show more
Finish	Other
Material	Fabric Glass wool
Shape	Rectangle Square Circle Diamond Hexagon Kite Octagon Oval Parallelogram Triangle Other Pentagon Rhombus Trapezium Trapezoid Formless Elliptical Show more
Length	1200 mm
Width	900 mm 2100 mm 1200 mm 2400 mm 1800 mm 2700 mm 3000 mm Show more
Height	25 mm 40 mm
Warranty description	25 year

Uniclass	Pr_35_93_13_80 Sound attenuator infill unitsPrimary
CAWS	K13/170 Acoustic panel lining K13/170 Acoustic panel lining

Specification data - Sound attenuator infill units

Classification data
Form	Panel.
Rigidity	Rigid.
Application	Wall mounting.
Material	Recycled glass wool core, fabric wrapped.
Acoustic performance	-
Purpose	Absorber.
Sound absorption	Class A (40 mm thickness). Class C (24 mm thickness).
Fire performance	-
Reaction to fire	Recycled glass wool core material meets Class 0 Fire Rating Standard BS476: Part 6.
Dimensions	-
Size (length x width)	1200 x 900 mm. 1200 x 2100 mm. 1200 x 2400 mm. 1200 x 1800 mm. 1200 x 1200 mm. 1200 x 2700 mm. 1200 x 3000 mm. Guidance for specification option: 40 mm thick only.
Thickness (overall)	25 mm. 40 mm.
Profile	Bush. Chain link. Circle. Drop. Ellipse. Gear. Hexagon. Jewel. Leaf. Plus. Radiator. Rectangle. Seedling. Shell. Slate. Soft rectangle. Soft square. Square. Stone. Triangle. Wall panel opener.
Edges	Square.
Surface pattern	Solid. Other. Guidance for specification option: Can be printed with company logo to corporate images, in-house graphics and photos etc. Consult manufacturer and insert requirements.
Finish	Camira Cara. Guidance for specification option: Composition: 100% polypropylene. Environment: Certified to the EU Ecolabel. Flammability: EN 1021-1, BS 476 Parts 7 Class 1, EN 13501-1 Adhered Class B,s2,d0. Camira Lucia. Guidance for specification option: Composition: 100% non-metallic recycled polyester. Environment: Certified to the EU Ecolabel; certified to OEKO-TEK Standard 100. Flammability: EN 1021-1 and 1021-2; BS 7167; BS 476 Parts 7 Class 1; EN 13501-1 adhered Class B,s2,d0; EN 13501-1 un-adhered Class B,s1,d2. Camira Era. Guidance for specification option: Composition: 100% polyester. Environment: Certified to OEKO-TEK Standard 100; certified to Indoor Advantage ™ Gold. Flammability: EN 1021-1 and 1021-2; BS 7167; EN 13501-1 adhered Class B,s1,d0; EN 13501-1 un-adhered Class C,s1,d0. Camira Blazer. Guidance for specification option: Composition: 100% virgin lambswool. Environment: Rapidly renewable and compostable. Flammability: EN 1021-1 and 1021-2; BS 7167; NF D 60-013; ONORM B 3825 and A 3800-1; UNI 9175 Class 1; BS 476 Parts 7 Class 1; EN 13501-1 adhered Class D,s1,d0. Camira Blazer Lite. Guidance for specification option: Composition: 100% virgin lambswool. Environment: Certified to Indoor Advantage™ Gold; Rapidly renewable and compostable. Flammability: BS 476 Part 7 Class 1; BS 476 Part 6 Class 0; EN 13501-1 (SBI) adhered Class C,s1,d0. Camira Sonus. Guidance for specification option: Composition: FHR & SJR – 72% polyester, 18% polyamide, 10% viscose; FHU & SJE – 57% polyester, 43% polyamide. Environment: Certified to Indoor Advantage™ Gold. Flammability: EN 1021-1; EN 13501-1 (SBI) adhered Class C,s1,d0 (Etch).
Colour	- Manufacturer guidance Available in a range of more than 80 colours and textures. Consult manufacturer for details and insert requirements.
Accessories	Fittings for independent suspension.

Sustainability data

Contains Red List materials	No
Material	Fabric Glass wool

Literature

Brochure PanelHush Fabric Wall Panels
