Solid, flat, UV protected polycarbonate sheet.

Jump to:
+44 (0)1302 360161 www.palram.com

Application

  • Architectural roofing.
  • Covered walkways.
  • Fabricated items.
  • Light boxes and designed signage.
  • Skylights.
  • Transparent acoustic barriers.

Description

PALSUN® combines ultra-high impact resistance with clarity, making it the material of choice for demanding applications. Virtually unbreakable, yet it is transparent as glass at less than half its weight. It can be cold bent and easily fabricated and formed, making it ideal for barrel vault roofing, skylights, architectural roofing and glazing. Clear, translucent and opaque sheets are also ideal as machine guards, sound barriers, anti-vandal and safety glazing. PALSUN® Diffuser and LB sheets are extensively used in durable light boxes.


Features and benefits:

  • Blocks harmful UV radiation.
  • Easy to handle and install.
  • Good acoustical insulation.
  • High clarity and light transmission.
  • High impact resistance - virtually unbreakable.
  • Lightweight.
  • Versatile and formable.
  • Weather and UV resistant.
  • Wide service temperature range.

General information

Shape

Rectangle

Color

Black

Blue

Brown

Clear

Cream

Show more

Material

Polycarbonate

Size

1220 x 2440 mm

1250 x 2440 mm

2050 x 3050 mm

2450 x 3050 mm

Uniclass

Pr_25_71_63_18 Composite and recycled plastics sheetsPrimary

CAWS

B91/330 Canopy

B91/335 Covered walkway

H30/160 Profiled plastic sheet rooflights or wall lights

H30/30 Air and vapour control membrane

H31/160 Profiled plastics sheet

H31/30 Profiled plastics sheet

Specification data - Composite and recycled plastics sheets

Material

-

Thermoplastics

Polycarbonate.

Dimensions

-

Length

2440 mm.

3050 mm.

Width

1220 mm.

1250 mm.

2050 mm.

2450 mm.

Sheet thickness

2 mm.

3 mm.

4 mm.

5 mm.

6 mm.

8 mm.

10 mm.

Colour

Colour/ Finish:

PALSUN® is available in a wide variety of transparent, translucent and opaque colours. Opaque colours do not transmit light, whereas clear or tinted transparent colours transmit light and images. Clear and opaque sheets may have a glossy or embossed surface on one side. Opal or Diffuser sheets have 8–86% light transmission depending on the type of tint and the thickness of the sheet. SolarSmart™ cool-light sheets transmit fixed amounts of light (20, 35 or 50%) while reducing heat build up by filtering near-infrared radiation that generates heat.

- Opaque:

Black, Brown, Cream (RAL 9001), Dark Blue, Dark Green, Dark Grey, Light Grey (RAL 7035), Off White, Red Brick.

- Translucent:

Mint Green, Red, Solar Control (SolarSmart™ sheets for use with PALSUN® Solar Control), Solar Ice, Solar Olympic (SolarSmart™ sheets for use with PALSUN® Solar Control), White Diffuser, White Opal, Yellow.

- Transparent:

Blue, Bronze, Clear, Green, Red, Smart Blue (SolarSmart™ ), Smart Green (SolarSmart™ ), Smart Grey (SolarSmart™ ), Solar Grey Bluish Breeze (Solar Smart™).

Black.

Blue.

Bronze.

Brown.

Clear.

Cream (RAL 9001).

Dark Blue.

Dark Green.

Dark Grey.

Green.

Light Grey (RAL 7035).

Mint Green.

Off White.

Red Brick.

Red.

Solar Ice.

White Diffuser.

White Opal.

Yellow.

Fire performance

To BS EN 13501, B, s1, d0.

PALSUN® FR has a higher fire resistance rating of V-0 to UL94.

Density

Test method D-792.

1.2 g/cm³.

Elongation

Test method D-638.

6% at yield, >80% at break.

10 mm/min.

Flexural strength

Test method D-790.

93 MPa.

1.3 mm/min.

Light transmission

Opaque.

Black, Brown, Cream (RAL 9001), Dark Blue, Dark Green, Dark Grey, Light Grey (RAL 7035), Off White, Red Brick.

Translucent.

Mint Green, Red, Solar Control (SolarSmart™ sheets for use with PALSUN® Solar Control), Solar Ice, Solar Olympic (SolarSmart™ sheets for use with PALSUN® Solar Control), White Diffuser, White Opal, Yellow.

Transparent.

Blue, Bronze, Clear, Green, Red, Smart Blue (SolarSmart™ ), Smart Green (SolarSmart™ ), Smart Grey (SolarSmart™ ), Solar Grey Bluish Breeze (Solar Smart™).

Modulus of elasticity

Test method D-638.

2300 MPa.

Tensile, 1 mm/min.

Service temperature range

-50 to +100°C.

Sheet size

1220 x 2440 mm.

1250 x 2440 mm.

2050 x 3050 mm.

Not available for 1–1.5 mm thickness.

2450 x 3050 mm.

TensileStrength

Test method D-638.

62.5 MPa at yield, 65 MPa at break.

ThermalConductivity

Test method C-177.

0.21 W/mK.

Type

UV protected on one side.

Literature

Palsun - Flat Solid Polycarbonate Sheet

Palsun - Flat Solid Polycarbonate Sheet

Third party certifications

  • ISO: 9001 2008
  • ISO: 14001:2004
  • BS EN: 13501 B-s1-d0
  • REACH compliant
  • RoHS compliant
