O.Novo WC Complete 5660H1
Verified by manufacturer 8 months ago
Combi-Pack, oval.
Application
WC suitable for wall mounting.
Description
Oval WC combi-pack manufactured in accordance with EN 997.
Features and benefits:
- Manufactured from sanitary ceramics.
- Flush volume: 3/ 4.5 L.
- Horizontal outlet.
- Wall mounted.
- The pack includes a washdown WC 5660, WC seat with quick release and soft-closing hinges 9M38 S1 01.
- LEED: 4.
General information
Color | White |
Material | Ceramic Guidance for specification option: Sanitary ceramics |
Shape | Oval |
Length | 560 mm |
Width | 360 mm |
Height | 350 mm |
Uniclass | |
CAWS | N13/10 WC pans and flushing arrangements N13/300 WCs and cisterns |
Product range |
Specification data - WC suites
Standards | |
Cisterns | To BS EN 997. |
Pans | To BS EN 997. |
Form | 5660H1, wall mounted.Guidance for specification option: Standard. 5660HR DirectFlush, wall mounted.Guidance for specification option: Not suitable for installation with flush valves. Consult manufacturer for details. |
Materials | |
Body | Ceramic. |
Finish and colour | White Alpin.White Alpin CeramicPlus.Guidance for specification option: A special process gives the CeramicPlus surface a permanent high-quality finish and offers optimum hygiene performance. |
Sizes | |
Cistern capacity | 3/4.5 L dual flush. |
Pan height | 350 mm. |
Weight | 18 kg. |
Sustainability data
Material | Ceramic Guidance for specification option: Sanitary ceramics |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 2 |
 ARCHICAD | - | 1 |
