Novia VC200 Reflective Air and Vapour Control Layer

Verified by manufacturer 6 days ago

Novia Ltd

Reflective, airtight vapour-control layer (AVCL).

Jump to:
01795 515 110 Website

Application

Suitable for use in insulated wall, roof and floor applications requiring high moisture resistance. Also suitable for use in conjunction with Novia breather membranes for insulated frame applications.

Description

A highly reflective airtight vapour-control layer (AVCL) that delivers a low vapour permeability solution and helps to prevent interstitial condensation problems.


Features and benefits:

  • High performance air and vapour control layer.
  • High reflectivity/ low emissivity surface.
  • Low moisture permeability.
  • Maximizes the insulation performance.
  • Technically advanced laminate.
  • Delivers improved thermal resistance (R-values) and thermal transmittance (U-values).
  • Helps buildings to meet the requirements of BS 5250.
  • High quality, low cost solution.
  • CE approved to BS EN 13984.


Must be installed with Novia dual tape sealing system to provide a fully airtight seal. Consult manufacturer for information.


Tape:

  • For professional installation, all Novia® VCL products should be 100% fully sealed to the structure using a Novia® double-sided butyl tape and one of the foil or BOPP lap tapes. The wider the tape used, the stronger the final seal will be and the easier it will be to install.
  • Novia® recommends the 30 mm wide butyl tape and 60 mm metallised BOPP tape for all standard VCL installations.

General information

Color

Silver

Finish

Reflective

Shape

Rectangle

Length

50000 mm

Width

1500 mm

2700 mm

Uniclass

Pr_25_57_65_60 Plastics sheetsPrimary

CAWS

H20/150 Sheet cladding (attached to metal support systems)

H30/261 Air and vapour control membrane

H30/30 Air and vapour control membrane

H31/261 Air and vapour control membrane

H31/45 Air and vapour control membrane

H92/780 Air and vapour control layer

J21/395 Air and vapour control layer

J31/330 Air and vapour control layer

J41/395 Air and vapour control layer

J42/395 Air and vapour control layer

K10/155 Wall lining system (metal studs)

K11/115 Battened plywood floating floor

K11/125 Battened particleboard floating floor

K11/135 Battened oriented strand board floating floor

K11/145 Battened cement-bonded particleboard floating floor

K11/215 Plywood floating floor

K11/225 Particleboard floating floor

K11/235 Oriented strand board floating floor

K11/245 Cement bonded particleboard floating floor

K11/795 Wall lining on metal framing

K21/110 Wood flooring

K21/111 Wood floating floor

K21/115 Wood laminate flooring

K21/120 Battened wood flooring

K21/130 Battened wood floating floor

K21/140 Battened wood laminate flooring

K21/145 Composite laminate flooring

K21/146 Laminate flooring

P10/310 Air and vapour control layer

P10/60 Air and vapour control layer

Product range

Vapour Control Layers

Specification data - Plastics sheets

Purpose

Airtight vapour control layer (AVCL).

Performance characteristics

-

Tensile strength (minimum)

MD/ CD to EN 12311-1, 235/120 N/50 mm.

Tear resistance

MD/ CD to EN 12310-1, 125/150 N.

Elongation to break

MD/ CD to EN 12311-2, 125/7%.

Water vapour resistance (minimum)

To EN 1931, 200 m.

Manufacturer guidance

Water vapour permeability.

Fire performance

To EN 13501-1, Class E.

Manufacturer guidance

Reaction to fire.

Root inhibitor

To EN 1849-2, 82 g/m².

Manufacturer guidance

Nominal weight.

Physical properties

-

Weight (minimum)

6.5 kg.

Dimensions

-

Width (minimum)

1500 mm.

Roll length (minimum)

50 m.

Standard:

CE approved to BS EN 13984.

Resistance to water penetration

Requirement achieved to EN 1928.

Reflectivity

95% to EN 15976.

Tape

Novia Double Sided Butyl Tape.

Novia Metallised BOPP Tape.

Novia Foil Tape.

Sustainability data

Contains Red List materials

No
