Niveus - Clay Facing Brick
Verified by manufacturer 4 months ago
A sandcreased brick.
Description
A sandcreased facing brick.
Features and benefits:
- Brick pack quantity (430).
- Brick packs supplied banded (plastic and shrink-wrapped .
- Brick voids: 8–13.
- EAN number: 5036335113295.
- Factory: Leicester Factory.
- Stock.
General information
Color | Yellow Guidance for specification option: Buff. |
Finish | Sandcreased |
Material | Clay |
Shape | Rectangle |
Length | 215 mm |
Width | 102 mm |
Height | 65 mm |
Uniclass | |
CAWS | F1/304 Facing bricks F10/110 Clay facing brickwork F10/5 Facing brickwork |
SKU Code | A0083A |
GTIN/EAN | 5036335113295 |
Specification data - Clay bricks
Classification data | |
Standard | To BS EN 771-1. |
Brick description | Sandcreased facing brick. |
Work size (length x width x height) | 215 x 102 x 65 mm. |
Tolerances | |
Mean value | T2. |
Range | R1. |
Compressive strength | |
Mean compressive strength (minimum) | 15 N/mm². |
Durability designation | F2. |
Density | |
Gross dry | 1310 kg/m³. |
Net dry | 1500 kg/m³. |
Water absorption | 25%. Guidance for specification option: Brick suction 3.1. |
Configuration | Frogged. Guidance for specification option: Single frog. |
Thermal conductivity | 0.65 W/mK. |
Water vapour permeability | 5/15 µ. Manufacturer guidanceTo BS EN 1745. |
Bond strength | 0.15 N/mm². |
Reaction to fire | Euroclass A1. |
Active soluble salts | S2. |
Weight | 2 kg. |
Colour | Buff. |
Type | Stock. |
Sustainability data
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Material | Clay |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 IFC | - | 1 |
 Revit | - | 1 |
