Natural Slate GALLEGAS by CUPA 39

Name: Natural Slate GALLEGAS by CUPA 39
Brand: SIGA Natural Slate
SKU: 5ZvDENesHBL144kXdFijro

Verified by manufacturer today

SIGA Natural Slate

Product certifications:

DoP
Certificate type

A very popular slate for use on all projects across the UK, with a blue grey textured finish.

Jump to:

Request BIM

01480 302500 Website

Application

Heritage, Self Build, Conversion/Refurbishment, Housing Developments

Description

Gallegas by CUPA 39 is a first selection slate which is flat, uniform and of consistent thickness. With a blue/grey textured finish, it is a suitable choice for new build and refurbishment projects. Minimal sorting is required which enables fast paced installation, contributing to its popularity.

Part of the Excellence Range

Region Used: National

Product Applications: Heritage, Self Build, Conversion/ Refurbishment, Housing Developments.

Source: San Vicente, Spain.

Colour: Blue Grey.

Texture: Smooth.

Warranty: 100 Year Warranty, T&C's apply. Must be registered for within 4 weeks of installation.

Features and benefits:

Full technical support and guidance is available.
Meets the requirements of NHBC Standards.
Conform to BS EN 12326-1:2014 – T1/S1/W1.

General information

Color	Blue Grey
Finish	Smooth
Material	Slate
Shape	Rectangle
Length	400 mm 500 mm
Width	250 mm 375 mm
Height	5.5 mm
Warranty description	100 year Guidance for specification option: Manufacturer's T&C's apply. Must be registered for within four weeks of installation.

Uniclass	Pr_25_93_72_56 Natural slatesPrimary
CAWS	H62/3 Roof slating H62/10 Vertical slating H62/105 Roof slating H62/120 Vertical slating

SKU Code	Gallegas by CUPA 39

Specification data - Natural slates

Classification data
Slate type	-
Source	Spanish.
Colour	Blue/ grey.
Standards	-
Product specification	To BS EN 12326-1.
Methods of test	To BS EN 12326-1.
Properties	-
Type	Very Flat.
Dimensional tolerances	Deviations from declared length, width, edge straightness, rectangularity, and flatness are not to exceed values specified in BS EN 12326-1, clause 5.12.
Nominal thickness and individual thickness variation	5 mm ±35%.
Characteristic modulus of rupture (Transverse)	48.2 N/mm².
Characteristic modulus of rupture (Longitudinal)	43.9 N/mm².
Water absorption	Code W1 (<0.6%).
Freeze-thaw resistance	No test required.
Thermal cycle test	Code T1.
Carbonate content	Less than 20%.
Sulfur dioxide exposure test	Code S1.
Non-carbonate carbon content (maximum)	Less than 2%.
Reaction to fire	Class A1 (EC decision 96/ 603/ EC as amended).

Sustainability data

Contains Red List materials	No
Country of material origin	Spain
Country of product manufacture	Spain
Material	Slate
Carbon dioxide equivalent
Carbon dioxide equivalent, as defined in BS EN 15804 Self-declared
Stage Normalised unit (kg CO₂ eq/kg) Declared unit (kg CO₂ eq/m²) Stage:A1–A3 ('Production stage') Normalised unit : Declared unit : 4.01
Recyclability	Undamaged slates are salvaged and reused.
Recycled content As defined in clause 7.8 of BS EN ISO 14021	0 %
Expected Life	75 year
