Namaka Granite Paving

Verified by manufacturer 30 days ago

Polished

Marshalls plc Variant:

Sawn granite paving from China with green / grey tones.

Jump to:
+44 (0)330 0574472 Website

Application

Available as paving, setts, tactile paving, bespoke masonry and street furniture – consult manufacturer for details. Colour variations and markings are characteristic of natural stone.

Suitable for vehicular trafficked and pedestrian areas.

Description

Sawn granite paving from China, with predominantly green / grey tones and other inclusions.


Features and benefits:

  • Hard-wearing and strong.
  • Attractive appearance - provides a modern aesthetic.
  • Available in two finishes.
  • Has non-slip/ skid properties.
  • Can be used as a standalone product or mixed with other colours / products from the manufacturer's range.
  • UKCA marked and manufactured in accordance with BS EN 1341:2012.
  • Also available as setts, tactile paving, bespoke masonry and street furniture – consult manufacturer for details. Colour variations and markings are characteristic of natural stone.

General information

Color

Green

Grey

Manufacturer guidance

Includes predominant green/ grey tones and various other inclusions.

Finish

Flamed

Fine

Guidance for specification option:

Fine picked.

Material

Granite

Shape

Rectangle

Square

Length

200 mm

300 mm

450 mm

600 mm

900 mm

Show more

Width

100 mm

150 mm

200 mm

450 mm

600 mm

Show more

Height

50 mm

60 mm

70 mm

Bespoke

Uniclass

Pr_25_93_60_58 Natural stone paving slabsPrimary

CAWS

Q25/310 Natural stone slabs

Q25/26 Natural stone slab paving system

Specification data - Natural stone paving slabs

Standard

To BS EN 1341.

Stone denomination

-

Petrological family

Granite.

Colour

Grey green medium to slightly coarse grained.

Name (traditional)

Monzonite.

Origin

China.

Guidance for specification option:

Fujian Province.

Physical properties

-

Dimensions and associated tolerances

-

Nominal sizes

200 x 100 x 50 mm.

200 x 100 x 60 mm.

200 x 100 x 70 mm.

300 x 100 x 50 mm.

300 x 100 x 60 mm.

300 x 100 x 70 mm.

300 x 150 x 50 mm.

300 x 150 x 60 mm.

300 x 150 x 70 mm.

300 x 200 x 50 mm.

300 x 200 x 60 mm.

300 x 200 x 70 mm.

450 x 450 x 50 mm.

450 x 450 x 60 mm.

450 x 450 x 70 mm.

600 x 600 x 50 mm.

600 x 600 x 60 mm.

600 x 600 x 70 mm.

900 x 450 x 50 mm.

900 x 450 x 60 mm.

900 x 450 x 70 mm.

900 x 600 x 50 mm.

900 x 600 x 60 mm.

900 x 600 x 70 mm.

Tolerances on plan dimension and thickness (nominal)

Class 1.

Guidance for specification option:

Paving Class 1 tolerances to all dimensions as standard. Setts Class 2 tolerances to all dimensions as standard. Kerbs Class 2 tolerances to all dimensions as standard. Others by agreement.

Tolerances on diagonals

Class 1.

Guidance for specification option:

Paving Class 1 tolerances to all dimensions as standard. Setts Class 2 tolerances to all dimensions as standard. Kerbs Class 2 tolerances to all dimensions as standard. Others by agreement.

Tolerances on thickness

Class 1.

Guidance for specification option:

Paving Class 1 tolerances to all dimensions as standard. Setts Class 2 tolerances to all dimensions as standard. Kerbs Class 2 tolerances to all dimensions as standard. Others by agreement.

Finish

Polished.

Performance requirements

-

Slip resistance

To BS 14231, 65 (dry); 25 (wet).

Breaking load

To EN 12372, 15.84 MPa.

Guidance for specification option:

(Lev = 13.53 MPa).

Water absorption (maximum)

To EN 13755, 0.10%.

Guidance for specification option:

(Hev = 0.21%).

Abrasion resistance

To EN 14157, 15 mm.

Guidance for specification option:

(Hev = 16 mm).

Durability

To EN 12371, 28.3/27.1 MPa.

Manufacturer guidance

Freeze-thaw.

Density

To EN 1936, 2975 kg/m³.

Porosity

To EN 1936, 0.10%.

Manufacturer guidance

Open porosity.

CompressiveStrength

To EN 1926, 109 MPa.

Guidance for specification option:

(Lev = 78.99 MPa).

Water absorption

To EN 13755, 0.10%.

Guidance for specification option:

(Hev = 0.21%).

Light reflectance

11.76.

Surface roughness

1.94 Rz-μm.

Sustainability data

Country of material origin

China
