Namaka Granite Paving

Name: Namaka Granite Paving
Brand: Marshalls plc
SKU: 78g69KG3yBoAaJZG9jH82A

Verified by manufacturer 3 months ago

Polished

Marshalls plc

Sawn granite paving from China with green / grey tones.

Jump to:

+44 (0)330 0574472 Website

Application

Available as paving, setts, tactile paving, bespoke masonry and street furniture – consult manufacturer for details. Colour variations and markings are characteristic of natural stone.

Suitable for vehicular trafficked and pedestrian areas.

Description

Sawn granite paving from China, with predominantly green / grey tones and other inclusions.

Features and benefits:

Hard-wearing and strong.
Attractive appearance - provides a modern aesthetic.
Available in two finishes.
Has non-slip/ skid properties.
Can be used as a standalone product or mixed with other colours / products from the manufacturer's range.
UKCA marked and manufactured in accordance with BS EN 1341:2012.
Also available as setts, tactile paving, bespoke masonry and street furniture – consult manufacturer for details. Colour variations and markings are characteristic of natural stone.

General information

Color	Green Grey Manufacturer guidance Includes predominant green/ grey tones and various other inclusions.
Finish	Flamed Fine Guidance for specification option: Fine picked.
Material	Granite
Shape	Rectangle Square
Length	200 mm 300 mm 450 mm 600 mm 900 mm Bespoke Show more
Width	100 mm 150 mm 200 mm 450 mm 600 mm Bespoke Show more
Height	50 mm 60 mm 70 mm Bespoke

Uniclass	Pr_25_93_60_58 Natural stone paving slabsPrimary
CAWS	Q25/310 Natural stone slabs Q25/26 Natural stone slab paving systems

Specification data - Natural stone paving slabs

Standard	To BS EN 1341.
Stone denomination	-
Petrological family	Granite.
Colour	Grey green medium to slightly coarse grained.
Name (traditional)	Monzonite.
Origin	China. Guidance for specification option: Fujian Province.
Physical properties	-
Dimensions and associated tolerances	-
Nominal sizes	200 x 100 x 50 mm. 200 x 100 x 60 mm. 200 x 100 x 70 mm. 300 x 100 x 50 mm. 300 x 100 x 60 mm. 300 x 100 x 70 mm. 300 x 150 x 50 mm. 300 x 150 x 60 mm. 300 x 150 x 70 mm. 300 x 200 x 50 mm. 300 x 200 x 60 mm. 300 x 200 x 70 mm. 450 x 450 x 50 mm. 450 x 450 x 60 mm. 450 x 450 x 70 mm. 600 x 600 x 50 mm. 600 x 600 x 60 mm. 600 x 600 x 70 mm. 900 x 450 x 50 mm. 900 x 450 x 60 mm. 900 x 450 x 70 mm. 900 x 600 x 50 mm. 900 x 600 x 60 mm. 900 x 600 x 70 mm.
Tolerances on plan dimension and thickness (nominal)	Class 1. Guidance for specification option: Paving Class 1 tolerances to all dimensions as standard. Setts Class 2 tolerances to all dimensions as standard. Kerbs Class 2 tolerances to all dimensions as standard. Others by agreement.
Tolerances on diagonals	Class 1. Guidance for specification option: Paving Class 1 tolerances to all dimensions as standard. Setts Class 2 tolerances to all dimensions as standard. Kerbs Class 2 tolerances to all dimensions as standard. Others by agreement.
Tolerances on thickness	Class 1. Guidance for specification option: Paving Class 1 tolerances to all dimensions as standard. Setts Class 2 tolerances to all dimensions as standard. Kerbs Class 2 tolerances to all dimensions as standard. Others by agreement.
Finish	Polished.
Performance requirements	-
Slip resistance	To BS 14231, 65 (dry); 25 (wet).
Breaking load	To EN 12372, 15.84 MPa. Guidance for specification option: (Lev = 13.53 MPa).
Water absorption (maximum)	To EN 13755, 0.10%. Guidance for specification option: (Hev = 0.21%).

Abrasion resistance	To EN 14157, 15 mm. Guidance for specification option: (Hev = 16 mm).
Durability	To EN 12371, 28.3/27.1 MPa. Manufacturer guidance Freeze-thaw.
Density	To EN 1936, 2975 kg/m³.
Porosity	To EN 1936, 0.10%. Manufacturer guidance Open porosity.
CompressiveStrength	To EN 1926, 109 MPa. Guidance for specification option: (Lev = 78.99 MPa).
Water absorption	To EN 13755, 0.10%. Guidance for specification option: (Hev = 0.21%).
Light reflectance	11.76.
Surface roughness	1.94 Rz-μm.

Sustainability data

Country of material origin	China
