MuteClip® Acoustic Ceiling Systems - Ceiling Soundproofing System

Name: MuteClip® Acoustic Ceiling Systems - Ceiling Soundproofing System
Brand: iKoustic
SKU: jQC8iVVGTFqHSKuq96y7nB

Verified by manufacturer 10 days ago

MuteClip® Double - Gold

iKoustic

Acoustic ceiling for commercial and residential environments.

Jump to:

+44 (01937) 588 226 Website

Application

Suitable for residential, commercial, and specialist spaces requiring reduction of noise transfer between floors via the ceiling.
For use with timber joist or concrete ceiling structures in both new build and retrofit applications.

Description

iKoustic® Ceiling Systems provide high-performance acoustic solutions for reducing airborne and impact sound transmission through ceiling constructions in residential, commercial, and specialist applications. Each system is engineered for maximum sound isolation, simple installation, and long-term reliability.

Features and benefits:

Significantly reduces airborne and impact sound between rooms and floor levels.
Designed for use with existing timber joist, concrete slab, and metal frame ceiling constructions.
Suitable for both suspended and direct-fix ceiling applications.
Incorporates dense acoustic materials and isolation components to effectively decouple and block sound paths.
Offers a range of solutions including:
- MuteClip® Ceiling Systems: Utilises iKoustic’s unique MuteClip® and Channel to create a fully decoupled ceiling system with excellent acoustic performance.
- MuteBoard™ Systems: High-mass acoustic boards ideal for direct-to-joist or direct-to-surface installations.
Ideal for new builds, refurbishments, sound testing compliance (Approved Document E), and sensitive heritage or listed buildings.
Slimline build-up options available to minimise ceiling height loss.
Products manufactured using recycled materials where possible, supporting sustainable construction practices.

General information

Color	White Grey Beige Brown Black
Finish	Other
Material	Plasterboard Mineral wool
Shape	Rectangle Other
Length	Bespoke
Width	34 mm 74 mm
Height	Bespoke

Uniclass	Ss_25_25_75_05 Acoustic panel lining systemsPrimary
CAWS	K13/170 Acoustic panel lining K13/170 Acoustic panel lining K10/245 Ceiling lining on timber

Specification data - Acoustic panel lining systems

System performance	Acoustic performance
Battens	MuteClip® channel. Guidance for specification option: The MuteClip® Channel clicks into the MuteClip®, providing a slimline and ‘de-coupled’ frame for plasterboards to be attached to.
Acoustic insulation	Mineral wool slab insulation.
Panelling	-
Type	1 x acoustic plasterboard panel with Tecsound® SY70. Guidance for specification option: Tecsound®: A flexible, easy to handle and high performing acoustic membrane for soundproofing.
Surface material	Plasterboard.
Surface finish	- Manufacturer guidance Consult manufacturer and insert requirements or omit.
Fasteners	- Manufacturer guidance Consult manufacturer and insert requirements.
System accessories	- Manufacturer guidance Consult manufacturer and insert requirements or omit.

Clip	MuteClip®. Guidance for specification option: The MuteClip® is backed with dual-density silicone. This acts as a shock absorber surrounding the fixing and buffering the metal clip.
Width	74 mm.
Overall size	- Manufacturer guidance Consult manufacturer and insert requirements.
Noise reduction coefficient	20 dB. Guidance for specification option: This system achieves 20 dB reduction on a timber ceiling.

Sustainability data

Material	Plasterboard Mineral wool
Recyclability	Rockwool stone wool insulation can be recycled Guidance for specification option: Leftover Rockwool stone wool insulation and off-cuts can be recycled and transformed into new Rockwool insulation.
