MSCP Façade Mesh Systems - ContraClad Architectural Perforated Mesh Facades
Verified by manufacturer 3 days ago
Versatile and dynamic architectural façade system.
Application
- Multi-storey car parks, (MSCP)
- Fire Exit Stair Wells
- Decorative Roof Plant Screens
- Ground Level and Bike/Cycle Enclosures
Description
Versatile and dynamic architectural façade system and screening solution to suit tailored project facade requirements.
General information
Color | Beige Black Bronze Copper Cream |
Finish | Powder-coated Mill Matt Gloss Satin |
Material | Aluminium |
Shape | Rectangle Diamond Kite Hexagon Octagon |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Uniclass | |
CAWS | H31/120 Metal profiled sheet self-supporting cladding/ roof covering H31/10 Metal |
Specification data - Decorative screen systems
Classification data | |
Cladding units | Bespoke. Rectangle. Round hole. Square. Triangle. Manufacturer guidancePerforated shapes. |
Secondary support structure | Aluminium Grade 6063T6/6082T6 brackets. Galvanized carbon steel S275 or similar) welded/ folded fabricated brackets. |
Primary fasteners | A2 stainless steel, with bi-metallic corrosion protection. |
Reaction to fire | Reaction to fire (if polyester powder coated): A2-s1-d0. |
Panel size | Manufacturer guidanceBespoke to suit LW/SW Pattern Dimension - See BIM Files for application types |
Panel depth | Manufacturer guidanceTypically 50 mm folded tray or to suit project or loading requirements - See BIM Files for application types |
Profiles | Bespoke to suit project requirements. Manufacturer guidanceHead/Jamb/Sill Profiles |
Mullion | 12-080-060MU,12-080-100MU, 11-050-050MU 12-100-045MU and 14-125-050ML. |
Panel Type | Folded Tray Panel for Hook-on or direct fix applications. Manufacturer guidancePanel Strengtheners: To suit project loading requirements - See BIM Files for application types. Insert requirements. |
Pattern | Manufacturer guidancePerforated pattern and spacing: Standard and bespoke patterns available, please consult manufacturer. |
Material: | 3 mm thick Aluminium - Typical grades 1050H14/H24, 5005, 55HX, J57S. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Europe |
Country of product manufacture | United Kingdom |
Material | Aluminium |
Recyclability | The global Recycling Efficiency Rate (RER) of aluminium is currently 76% |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | Manufacturer guidanceAvailable by request in low carbon aluminium billet/ingot maximum 4.0 kg CO2-equivalents per kg of aluminium |
Expected Life | 80 year |
