Application

Suitable for use as carrier of suspended platforms, travelling gantries and abseil trolleys.

Description

-NP01, NP35, NP03, NP04 and NP21 aluminium monorails:

These monorails are normally used as carrier of suspended platforms, travelling gantries and abseil trolleys. Manual, rope driven and electrical trolleys are available for monorails. In addition is the Norlift climbing trolley (CE approved) which climbs on the NP01 monorail. The climbing ability is achieved by using friction between the drive wheels and the monorail.


-NP33 and NP06 aluminium monorails:

These monorails are designed to be used for rope access work and carry traversing ladders and gantries. They are typically used for installations internally or externally to glazed atria.

General information

Color

Silver

Other

Guidance for specification option:

Can be powder coated.

Finish

Powder-coated

Galvanized

Mill

Material

Aluminium

Steel

Guidance for specification option:

Brackets.

Shape

Other

Length

Bespoke

Width

Bespoke

Height

Bespoke

Uniclass

Ss_80_30_25_50 Mobile rig monorail suspended access systemsPrimary

CAWS

N25/130 Gantry access system

Product range

Facade Access

Specification data - Mobile rig monorail suspended access systems

Monorail

Suspended access tracks.

Execution

Installing permanent suspended access systems.

Type

NP01.

Guidance for specification option:

The NP01 monorail system is the most flexible system in the range. It is used as carrier for many different applications and it can be installed hidden away on the roof or fixed to brackets on top of the facade. For most systems the monorail can have either mill finish, natural anodizing or be powder coated. For horizontal installations, NP01 have two 'families' of trolleys: capacity 400 and 600 kg.

  • Distance between brackets (maximum): 3.6 m.


Mounting position

To facade.

To roof.

To soffit.

To glazing.

Fixing background

To concrete.

To steelwork.

Rail finish

Anodized.

Mill finish.

Powder coated.

Guidance for specification option:

Consult manufacturer and insert requirements.

Support bracket

Galvanized mild steel.

Stainless steel.

Horizontal

Yes.

Manufacturer guidance

Horizontal bending.

Vertical

No.

Manufacturer guidance

Vertical bending.

Twisting

No.

Mounting

Side mounted.

Trolley

Electrical.

Guidance for specification option:

 NP35E.

Manual.

Guidance for specification option:

NP35M.

Rope driven.

Guidance for specification option:

NP35R.

Climbing trolley.

Guidance for specification option:

No.

Application method

Suspended platform, rope access, gantries and ladders.

Sustainability data

Recyclability

100%
