Mobicem Liquid Screed CT C25F5

Verified by manufacturer 2 months ago

Cemfloor Liquid Screeds Third party certifications:
  • EPD

    EPD

    Certificate type

  • ISO 14001 Environmental Management Systems

    Certificate type

  • ISO 9001 Quality Management

    Certificate type

A self levelling cementitious floor screed.

Jump to:
BIM object icon
01415 530 7587 Website

Application

Designed for use as a bonded thick levelling screed on concrete, as a floating screed over thermal or acoustic insulation with a minimum compressive strength of 100kPa, or as an unbonded screed on top of a plastic membrane.

Description

A self-levelling cementitious floor screed that complies with complies with EN 13813 and can be applied to a wide range of floors.


Mobicem Therm is delivered from a computerized automatic mobile mixing truck. The screed factory arrives on site with all the approved materials (sand, water, cement, Mobicem binder, admixture) and is mixed under factory production control.


Features and benefits:

  • Thinner sections compared to traditional screeds.
  • Larger floor area without joints.
  • Excellent thermal conductivity.
  • Reduced drying times (depending on drying conditions).
  • Self-compacting – no voids around underfloor heating pipes.
  • Can be applied in wet areas.
  • No risk of contamination at concrete mixing plants.
  • No surface laitance (dust) after curing.
  • Easy installation (reduces time and costs).
  • Floor flatness: SR2 (minimum).
  • Foot traffic after 24–48 hours.
  • In-situ crushing resistance (ISCR) test: Category A.

General information

Color

Grey

Finish

Cement

Material

Cementitious

The screed is a blend of Mobicem Binder, cement, sand and water.

Shape

Formless

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

Ten year

Uniclass

Pr_35_31_06_71 Ready-mixed levelling and wearing screedsPrimary
Ss_30_42_15_90 Unbonded cementitious levelling screed systems
Pr_35_31_06_78 Self-smoothing levelling screed mixes
Pr_35_31_06_69 Quick-drying levelling screed mixes
Pr_35_31_06_77 Screed flooring
Pr_35_31_06_12 Cementitious levelling screed mixes
Ss_30_42_15_10 Bonded or partially bonded cementitious levelling screed systems
Ss_30_42_15_30 Floating cementitious levelling screed systems

CAWS

M10/195 Proprietary screeds to BS EN 13813

M10/19 Proprietary screeds to BS EN 13813

Specification data - Ready-mixed levelling and wearing screeds

Standard

To EN 13813.

Binder type

Cementitious.

Compressive strength

C25.

Flexural strength

F5.

Density

Fresh density: 2100–2200 kg/m³.

Shrinkage

28 days.

<0.05%.

Screed thickness

20 mm (minimum).

Bonded

30 mm (minimum).

Unbonded

35 mm (minimum).

Floating over insulation: Residential

40 mm (minimum).

Floating over insulation: Commercial

40 mm (minimum) overall screed thickness, 25 mm above heating pipes.

Above conduits and heating pipes.

Sustainability data

Contains Red List materials

No

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Recyclability

Can be recycled to produce recycled aggregates for use in concrete.

EPD

BIM objects

BIM object icon

NBS BIM object standard

This BIM object has been authored to meet the requirements of the NBS BIM object standard.

Find out more about the NBS BIM object standard.

Platform Compatible Version
Revit
-

2

IFC
-

2
