Verified by manufacturer 5 months ago
EPD
Certificate type
ISO 9001 Quality Management
Certificate type
A self levelling cementitious floor screed.
Designed for use as a bonded thick levelling screed on concrete, as a floating screed over thermal or acoustic insulation with a minimum compressive strength of 100kPa, or as an unbonded screed on top of a plastic membrane.
A self-levelling cementitious floor screed that complies with complies with EN 13813 and can be applied to a wide range of floors.
Mobicem Therm is delivered from a computerized automatic mobile mixing truck. The screed factory arrives on site with all the approved materials (sand, water, cement, Mobicem binder, admixture) and is mixed under factory production control.
Features and benefits:
Color | Grey |
Finish | Cement |
Material | Cementitious Guidance for specification option: The screed is a blend of Mobicem Binder, cement, sand and water. |
Shape | Formless |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | Ten year |
Uniclass | |
CAWS | M10/195 Proprietary screeds to BS EN 13813 M10/19 Proprietary screeds to BS EN 13813 |
Standard | To EN 13813. |
Binder type | Cementitious. |
Compressive strength | C25. |
Flexural strength | F5. |
Density | Fresh density: 2100–2200 kg/m³. |
Shrinkage | <0.05%. Manufacturer guidance28 days. |
Screed thickness | 20 mm (minimum). Guidance for specification option: Bonded 30 mm (minimum). Guidance for specification option: Unbonded 35 mm (minimum). Guidance for specification option: Floating over insulation: Residential 40 mm (minimum). Guidance for specification option: Floating over insulation: Commercial 40 mm (minimum) overall screed thickness, 25 mm above heating pipes. Guidance for specification option: Above conduits and heating pipes. |
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Recyclability | Can be recycled to produce recycled aggregates for use in concrete. |
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
Platform | Compatible | Version |
---|---|---|
- | 2 | |
- | 2 |
Cemfloor Bonded Screed Detail
Cemfloor Floating Screed Detail
Cemfloor Screed Brochure
Cemfloor Screed On-Site Installation Procedures
Cemfloor Screed UnderFloor Heating Guidelines
Cemfloor Screed with UFH Detail
Cemfloor Therm Technical Data Sheet
Cemfloor Tiling- Floor Covering Guidelines
Cemfloor Unbonded Screed Detail
IS EN ISO14001:2015 Certification
ISO 9001: 2015 Certification
