Homogeneous high performing cleanroom vinyl floor covering in sheet form.

Jump to:
+44 (0)3332 412901 www.gerflor.co.uk

Application

Mipolam Biocontrol is a high performing commercial floor designed for cleanroom applications - ISO 4 and GMP-Class-A.

Description

Mipolam Biocontrol is a high performing homogeneous vinyl floor covering in sheet form designed for cleanroom applications. It is resistant to microbiological damage and has excellent resistance to chemicals and staining. Mipolam Biocontrol is coated with a photo-reticulated polyurethane surface treatment that provides surface finish and cleanability suitable for cleanroom contamination control. It particularly withstands hydrogen peroxide (H2O2) type decontamination processes. Suitable for high footfall and heavy loads, Mipolam Biocontrol is available in 16 non-directional colour references with a choice of vibrant and natural tones with a matt effect finish.


Features and benefits:

  • Cleanroom certified: for use in ISO 4 and GMP-Class-A cleanrooms.
  • Excellent resistance to staining and chemicals.
  • Integrated colour and non-directional design.
  • Suitable for high footfall and heavy static and dynamic loads.
  • Suitable for cleanroom contamination control cleaning methods (H2O2).
  • Highly flexible, easy to install and weld.
  • Compatible with the Gerflor Clean Corner system.
  • Range of colours – 16 references.
  • Contemporary matt finish.
  • 100% recyclable.
  • Also available in tile format: Mipolam Biocontrol Tile, specified separately.
  • ISO 14644-4 Resistance to gaseous H2O2 - BIOQUELL process: No alteration.


Installation and maintenance:

Should be installed in accordance with the BS 8203:2017 Code of practice for installation of resilient floor coverings. Installation and maintenance instructions are available. For optimum hygiene in cleanroom applications, Mipolam Biocontrol Sheet can be installed with the patented Clean Corner System.

General information

Finish

Matt

Color

See specification data for options.

Material

Vinyl

Size

2000 mm

Width

Uniclass 2015

Pr_35_57_71_67 Polyvinyl chloride (PVC) sheetsPrimary

CAWS

M50/150 Sheeting

M50/20 Sheeting

Product range

Sheeting / Homogeneous Flooring

Specification data - Polyvinyl chloride (PVC) sheets Enhanced data

Use class

To BS EN 685, class 34–43.

Commercial, very heavy – Light industrial, heavy.

Slip potential

-

Slip resistance value (SRV) (minimum)/ Pendulum test value (PTV) (minimum)

R9.

To DIN 51130.

Width

2000 mm.

Thickness

2 mm.

Colour and pattern

B-5303 Mixbeige.

B-5305 Garlic.

B-5306 Mixblue.

B-5310 Mixdim.

B-5312 White Pepper.

B-5320 Mixgrey.

B-5330 Smoke.

B-5332 Turmeric.

B-5341 Peanut.

B-5350 Slate.

B-5356 Indigo.

B-5357 Chervil.

B-5363 Cinnamon.

B-5366 Iris.

B-5375 Paprika.

B-5385 Safran.

Length

20 m.

Weight

2800 g/m².

Fire rating (to BS EN 13501)

Bfl-s1.

To EN 13501-1.

Static electricity

<2 kV.

To EN 1815 Static electrical propensity.

Clean room particle emission

ISO 4.

FRAUNHOFER Method.

VOC emissions (to ISO 16000-9)

4.7 μg/m²/hr.

ISO 16000-6,-9,-11 Air Purity (at 23°C).

Cleanroom

85.66% reduction in particulate contamination.

FRAUNHOFER Method/ ISO 14644-9 Particulate cleanability.

Cleanroom classification

A.

FRAUNHOFER Method/ 14698-1/GMP Microbiological cleanability.

Bacteria resistance (to EN846)

Inert and resistant.

ISO 846 /GMP Action of micro-organisms on the flooring.

Bacteriostatic.

ISO 846 / ISO14698-1 Micro-organism growth on the flooring.

Chemical resistance

Very good.

ISO 14644-4 Chemical resistance.

Product Reference

Mipolam Biocontrol – Sheet

Accessories

None.

Co-ordinating weld rods.

Environmental information

Recyclability

100%

Digital objects

Platform Compatible Version Certified to
Revit
-

1

2.1
IFC
-

1

2.1
Download now from NBS National BIM Library

Literature

Clean Corner System

Clean Corner System

Mipolam Bio Control/ Bio Control Performance Binder

Mipolam Bio Control/ Bio Control Performance Binder

Third party certifications

  • REACH: Compliant
  • Floorscore®: Certified
  • CE: Marked : Manufactured in accordance with EN 14041
  • BREAAM: A/A+
  • Fraunhofer Institute: Tested and certified
