Mini TS1203 Exposed Lever Chrome

Description

OPAC mini thermostatic concealed shower valve with chrome handle.


Features and benefits:

  • Single sequential control for both temperature and flow.
  • Anti-vandal stainless steel concealing plate.
  • Automatic thermostatic shut-off in the event of hot or cold water failure.
  • Check valves and serviceable filters as standard.
  • Supplied as ‘valve only’ and can be customized by choosing accessories.
  • Adjustable inlet centres of 99 mm (+/-1 mm).
  • Chrome plated to BS EN 248.


General information

Color

Silver

Finish

Chrome

Material

Brass

WarrantyDescription

One year

Uniclass 2015

Pr_40_20_87_81 Shower thermostatic water supply setsPrimary

CAWS

N13/375 Shower units

N13/40 Shower units

Product range

MINI 2 Range

Specification data - Shower thermostatic water supply sets Enhanced data

Approvals

Water Regulations Advisory Scheme (WRAS) approved, TMV2 Approved, TMV3 Approved.

Standards

To BS EN 1111 and BS EN 1287.

Form

Wall mounted thermostatic shower mixer valve.

Materials

-

Body

Brass.

Finish and colour

Chrome plated.

Flow rate (maximum)

8.3 L/ min at 3 bar.

Supply

Suitable for all plumbing systems (preferably balanced).

InletConnectionSize

15 mm compression elbows..

Outlet connector

½” BSP.

WorkingPressure

Minimum 0.2 bar, maximum 8 bar.

NominalStaticPressure

10 bar.

Digital objects

Platform Compatible Version Certified to
IFC

IFC2X3

2

1.3
Revit

Revit 2016

3

2.0
Download now from NBS National BIM Library

Literature

Thermostatic Mixing Valves

Thermostatic Mixing Valves

Third party certifications

  • WRAS certified: Certificate: 1404020
