Application

Suitable areas of application include:

  • Cash offices.
  • Retail.
  • Cash in transit.
  • Banks.

Description

They are typically used to transfer cash or valuables into and out of a secure area without opening a door to the secure area.

Features and benefits:

  • These products provide a modular solution for the transfer of cash or valuables.
  • Provides safety of cash by only allowing either the inner or outer doors to be interlocked or open and both doors cannot be open or closed at the same time.
  • Standard sizes and models to suit most applications, many bullet resistant models.
  • Can be simply and easily implemented.
  • Standard versions 20–25 cycles a day.
  • HD version up to 50 cycles a day.

Application:

Suitable areas of application include:

  • Cash offices.
  • Retail.
  • Cash in transit.
  • Banks.

General information

Finish

Powder coated RAL 7028 light grey

Material

Robust steel

Uniclass 2015

Pr_30_59_97_90 Transaction unitsPrimary

CAWS

N10/10 Purpose-made

N10/110 Purpose-made

Specification data - Transaction units

Product Reference

Meridian 35

470 x 310 x 615 mm (w x d x h), 58 kg.

Meridian 35HD

513 x 310 x 610 mm (w x d x h), 78 kg.

Meridian 70

428 x 450 x 650 mm (w x d x h), 71 kg.

Meridian 70HD

475 x 450 x 650 mm (w x d x h), 101 kg.

Meridian 100

508 x 693 x 600 mm (w x d x h), 125 kg.

Standard product features

Material:

Robust steel.

Construction:

Gas springs on both doors. Heavy duty pivot hinges, incorporating oilite bearings.

Finish:

Powder coated RAL 7028 light grey.

Resistance:

BS 5051 G2/S86.
