Mastic Asphalt Roofing - IKO Permaphalt - Mastic asphalt roofing

Verified by manufacturer 1 month ago

IKO Ireland Third party certifications:
  • NSAI Agrément Certificate

    NSAI Agrément Certificate

    Certificate type

Polymer modified mastic asphalt roof waterproofing.

Jump to:
+353 1 88 55 090 Website

Application

Suitable for insulated warm roofs, un-insulated cold roofs and inverted/ green roof configurations, balconies, terraces, podiums, zero fall roofs, biodiverse/brown roofs, roof gardens and blue roof specifications.

Description

A specially formulated mastic asphalt roofing using advanced polymer technology to provide a combination of long-term durability, increased fatigue resistance, improved temperature stability and ease of installation.


It can be applied to form a continuous waterproof covering over flat, sloped or curved surfaces. It can be worked round pipes, roof lights and other projections to provide a completely seam free membrane.


Features and benefits:

  • Complies with BS EN 12970:2000 – Mastic asphalt for waterproofing.
  • BBA Certified (89/2299).
  • Advanced polymer modification.
  • Broof(t4) Fire Classification.
  • Completely seamless waterproofing.
  • Long term durability.
  • Enhanced product stability across a wide temperature range.
  • Traditional application.
  • Manufactured under a BS ISO 9001 Quality Assurance Scheme.
  • Up to 25 year waterproofing guarantee.

General information

Color

Black

Material

Asphalt

Polymer

Length

Bespoke

Width

Bespoke

Height

20 mm

30 mm

Warranty description

25 year

Uniclass

Pr_35_31_05_72 Roofing, tanking and flooring mastic asphalt (MA)Primary

CAWS

J21/402 Mastic asphalt (roofing)

J21/26 Mastic asphalt

Specification data - Roofing, tanking and flooring mastic asphalt (MA)

Standard

To BS EN 12970.

Grade

Block (20 kg).

Grade of asphaltic cement

Polymer modified.

Colour

Black.

Thickness:

20 mm.

30 mm.

Mass

2.2 kg/m²/mm of thickness.

Expansion

Coefficient of cubic expansion: 15 x 10^-5/°C.

Vapour resistivity

Not less than 100,000 MN/g.

Water resistance

IKO Permaphalt is impervious to water.

Resistance to fire

To EN 13501-5, Broof(t4).

Movement

IKO Permaphalt is thermoplastic and is capable of accommodating normal movements encountered in well-designed building structures.

Guidance for specification option:

Structural movement joints within the roof will require the incorporation of a proprietary expansion joint which is compatible with a mastic asphalt roof waterproofing system.

Surface protection

With the exception of vertical and steeply sloping work, the finished IKO Permaphalt must be sand rubbed to reduce the incidence of crazing. A protective surface should be applied to all flat areas using a suitable solar reflective paint, stone chippings or promenade surfacing.

Guidance for specification option:

A protective surface should be applied to all flat areas using a suitable solar reflective paint, stone chippings or promenade surfacing.

Durability

Capable of lasting 50-60 years.

Outlets

IKO Elite Outlets.

Third-party certification

British board of agrement: 89/2299.

Sustainability data

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Material

Asphalt

Polymer

Third party certifications

NSAI Agrément Certificate

NSAI Agrément Certificate

23-0439-IKO-PERMAPHALT-ROOF-WATERPROOFING-SYSTEM

Literature

IKO Permaphalt Design Guide

IKO Permaphalt Design Guide

IKO Permaphalt Technical Data Sheet

IKO Permaphalt Technical Data Sheet

Brochure - IKO PLC ESG Report July 2023

Brochure - IKO PLC ESG Report July 2023

Case studies

Renewing the Mastic Asphalt Roof Coverings for the Westminster Cathedral - Carbon Neutral Project

Renewing the Mastic Asphalt Roof Coverings for the Westminster Cathedral - Carbon Neutral Project

Mastic Asphalt Roof Refurbishment for The Grade I Listed Building

Mastic Asphalt Roof Refurbishment for The Grade I Listed Building
