Application

Suitable for schools, open plan offices or other premises where strict demands are made on good acoustics and speech intelligibility.

Description

For applications requiring a ceiling which is mechanically secured to the structural soffit. Ecophon Focus F is installed directly to an existing plaster ceiling, boarding, battens or concrete, creating a ceiling with a smooth appearance. The bevelled edges create a narrow groove between each tile. The tiles are not demountable.

Features and benefits:

  • The tiles are manufactured from high-density glass wool.
  • The visible surface has an Akutex™ FT coating, and the back of the tile is covered with glass tissue.
  • The edges are painted.
  • The weight is approximately 2.5 kg/m².

Application:

Suitable for schools, open plan offices or other premises where strict demands are made on good acoustics and speech intelligibility.

General information
Features

The tiles are bonded edge-to-edge directly to the soffit surface, creating a ceiling with a smooth appearance. The bevelled edges create a narrow groove between each tile

Finish

Akutex FT – the surface allows almost 100% of the sound energy to penetrate into and be absorbed by the glass wool, providing optimum sound absorption. Reinforced and painted edges

Material

High-density glass wool

Shape

Square or rectangular

Size

Two sizes available

WarrantyDescription

Full warranty available upon request

Uniclass 2015 Raft or island suspended ceiling systems (Ss_30_25_22_70)
Specification data
Product Reference

Master F

Ceiling support

Direct-fix to soffit

Support fasteners

Connect™ screws

Ceiling units

Wall-to-wall ceiling/ floating ceiling

System accessories

None

Connect Angle Trim

White (wall-to-wall ceiling).

Connect Wood Trim

White (floating ceiling).

Panel -
Panel size (l x w)

600 x 600 mm

600 x 1200 mm

Thickness

20 mm

Colour/ Finish

White Frost

White 500, Nearest NCS colour sample S 0500-N, 85% light reflectance (of which more than 99% is diffuse reflection). Retro reflection coefficient 63 mcd/(m2lx). Gloss < 1.

Weight

2.5 kg/m² (approximate, including grid)

Overall depth of system (minimum)

20 mm

Indoor climate

Recommended by the Swedish Asthma and Allergy Association. Certified as A+ by French VOC. Emission classification of building materials: M1classification of building materials: M1

Moisture resistance

Class A, relative humidity 70% and 25°C, according to EN 13964:2014

Fire safety

Complies with BS EN 13501-1, Class A2-s1, d0

Sound absorption

In accordance with EN ISO 11654, Class C

Cleaning

The ceiling system can withstand daily dusting and vacuum cleaning, and weekly wet-wiping

Standard product features

Colour:

White.

Features:

The tiles are bonded edge-to-edge directly to the soffit surface, creating a ceiling with a smooth appearance. The bevelled edges create a narrow groove between each tile.

Finish:

Akutex FT – the surface allows almost 100% of the sound energy to penetrate into and be absorbed by the glass wool, providing optimum sound absorption. Reinforced and painted edges.

Material:

High-density glass wool.

Shape:

Square or rectangular.

Size:

Two sizes available.

Warranty description:

Full warranty available upon request.

Recycled content:

>59%.

Embodied carbon:

7.04 kg CO₂ equiv/m², in conformity with ISO 14025/ EN 15804.

Red Listed materials:

All Ecophon products are free from substances of very high concern (SVHC) and any compound on the list of REACH in the EU.

Country of origin:

Sweden, Finland or Poland.

Environmental information
Embodied carbon

7.04 kg CO₂ equiv/m², in conformity with ISO 14025/ EN 15804

Recycled content

>59%
