Markwik 21+ Panel Mounted Thermostatic Basin Mixer, Time Flow Sensor

Third party certifications:
  • QA Certificate

    Certificate type

Armitage Shanks

Panel-mounted thermostatic basin mixer with lever operation. Mainly used as a healthcare hospital mixer (TB H6).

Jump to:
+44 (0)870 122 8822 www.idealspec.co.uk
Description

Markwik 21+ panel mounted thermostatic basin mixer, time flow sensor, demountable with removable spout

  • Front access D-08 auditing & servicing
  • Conforms to HBN 04-01 Addendum 2014
  • Demount, submerge and disinfect
  • Bioguard against bacteria
  • Thermal disinfection feature
  • Available with fixed or removable spout
  • Timed flow sensor operation

General information
Finish

Chrome - (AA)

Color

Chrome

Features

Panel mounted thermostatic basin mixer, time flow sensor, demountable with removable spout

Panel mounted thermostatic basin mixer, single sequential lever, demountable with removable spout

Material

Brass

Shape

Cylindrical

Size

125 x 225 x 261 mm

WarrantyDescription

Manufacturers Warranty

Uniclass 2015
Pr_40_20_87_99 Washbasin thermostatic water supply setsPrimary
Specification data - Washbasin thermostatic water supply sets
Product Reference

A6684 - HBN 00-10 HTM64 (TB H6) Markwik 21+ Panel Mounted Thermostatic Basin Mixer, Time Flow Sensor

Markwik 21+ Panel Mounted Thermostatic Basin Mixer

A6737 - Markwik 21+ 1 hole thermostatic basin mixer, lever handle

Markwik 21+ Panel Mounted Thermostatic Basin Mixer

Finish

Chrome - (AA)

Ancillary

A6899 - Ancillary

Markwik 21+ Purging kit for panel mounted thermostatic mixers

Not required

Standard product features

Brassware:

  • Material: Chrome Plated Brass
  • Weight: 3.60 kg

Product Options

Mixer Tap is activated by hand movement over the sensor and water will run for a predetermined length of time. Factory pre-set at 1 minute but adjustable. Hygienic automatic flush can be set to occur every 6, 12, 24, 48 or 72 hours. Especially suited to medium and large hospital pattern integral back outlet basins and washing associated with clinical or nursing procedures. Fitted with an Armitage Bioguard outlet which reduces the opportunity for biofilm attachment and is lined with anti-microbial copper. Unique built-in thermal disinfection cleansing feature. Spout is removable for autoclave sterilisation. Body demounts for submergible disinfection. Suitable for high and low pressure systems. Flow rate regulated to maximum of 10 litres per minute. A separate purging kit is available to facilitate initial installation flushing and water sampling.

Digital objects
PlatformCompatibleVersionCertified to
Revit
Revit 2015 1 1.3
Download now from NBS National BIM Library
Third party certifications
  • http://www.buildcert.com/admin_buildcert/tmv3.php: TMV3
  • Water Regulations Advisory Scheme: WRAS : 1705015
