Mapeplan® T
Verified by manufacturer 3 months ago
Mapeplan® Af 12
Mapeplan® Af 12
Flexible polyolefin roofing waterproofing membranes.
Application
- Mapeplan® T Af: Suitable for use with adhered system for exposed roof installations.
- Mapeplan® T B: Suitable for loose laid ballasted, utility deck (pedestrian - parking) and roof garden systems.
- Mapeplan® T M: Suitable for exposed roof installations and for mechanical fixing.
Description
Synthetic roofing waterproofing membranes constructed from flexible polyolefin (FPO), produced in one multi-extrusion coating process with high quality raw materials. Conform to BS EN 13956.
General information
Material | FPO (flexible polyolefin) Glass Polyester |
Uniclass | |
CAWS | J42/10 Warm deck roof covering J42/110 Warm deck roof covering J42/120 Inverted roof covering J42/130 Cold deck roof covering J42/400 Waterproof membrane |
Specification data - Polymeric membranes
Material | Mapeplan® T Af: FPO (flexible polyolefin) reinforced with glass mat, fleece backed with 300 g/m² woven-non-woven polyester.Mapeplan® T B: FPO (flexible polyolefin) reinforced with glass mat.Mapeplan® T M: FPO (flexible polyolefin) reinforced with polyester net. |
Standard | To BS EN 13956. |
Width (minimum) | 1050 mm.Guidance for specification option: For Mapeplan® T M only. 1600 mm.Guidance for specification option: For Mapeplan® T M only. 2100 mm. |
Thickness (minimum) | 1.2 mm. |
Colour | High reflectance Smart White.Guidance for specification option: Top layer. Black.Guidance for specification option: Bottom layer. |
Roll length | Dependent on thickness. |
Joints | Joint peel resistance (to BS EN 12316-2): ≥300 N/50mm. Joint shear resistance (to BS EN 12317-2): Af and B: ≥500 N/50mm; M: ≥650 N/50mm. |
Water vapour diffusion resistance | μ, to BS EN 1931, 150 000. |
TensileStrength | To BS EN 12311-2, Af 15: ≥700 N/50mm; Af 18: ≥800 N/50mm; Af 15: ≥900 N/50mm; B 15, B 18 and B 20: ≥9 N/mm²; M 12, M 15, M 18 and M 20: ≥1100 N/50mm. |
Elongation at break | To BS EN 12311-2, Af: ≥65%; B: ≥550%; M: ≥15%. |
Resistance to tearing | To BS EN 12311-2, Af: ≥65%; B: ≥550%; M: ≥15%. |
Flexibility at low temperature | To BS EN 1109, ≤-40°C. |
Dimensional stability | To BS EN 1107-2, Af and B: ≤0.2%; M: ≤0.3%. |
Weight | 1.5 kg/m². |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
 IFC | - | 1 |
