Verified by manufacturer 6 months ago
Epoxy coatinused for the protection of floors, reservoirs and concrete pipes in contact with aggressive chemical agents such as acids, caustic solutions and hydrocarbons. FeRFA Type 2 – Floor coating.
Protection of floors, reservoirs and concrete pipes in contact with aggressive chemical agents such as acids, alkalis and hydrocarbons.
Coating applied in two coats with solvent free epoxy. Used on concrete floors, storage tanks and flumes which come into contact with aggressive chemicals such as acids and hydrocarbons. BS 8204-6: Type 2 floor classification. Typical thickness: 0.6–1.0 mm.
System includes:
Finish | Gloss |
Material | Epoxy resin |
Shape | Formless |
Uniclass | |
CAWS | M12/10 Resin flooring M12/110 Resin flooring M60/18 Special coating M60/195 Special coating |
Classification data | |
Material | Epoxy. |
Thickness | 0.6 mm. 1.0 mm. |
Colour | Grey. Neutral. Guidance for specification option: Can be coloured with Mapecolor paste. White. |
Mapecolor paste colour | Not required. RAL 1001 - Beige. RAL 1013 - Oyster white. RAL 1015 - Light ivory. RAL 3009 - Oxide red. RAL 5007 - Brilliant blue. RAL 5012 - Light blue. RAL 5016. RAL 5024 - Pastel blue. RAL 6001 - Emerald green. RAL 6017 - May green. RAL 6019 - Pastel green. RAL 6021 - Pale green. RAL 7001 - Silver grey. RAL 7030 - Stone grey. RAL 7032 - Pebble grey. RAL 7034 - Yellow grey. RAL 7035 - Light grey. RAL 7037 - Dusty grey. RAL 7040 - Window grey. |
Country of product manufacture | Italy |
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
Platform | Compatible | Version |
---|---|---|
![]() | Revit 2015 | 3 |
![]() | IFC2X3 | 2 |
