Mannok Therm Laminate Kraft - MLK

Third party certifications:
  • BBA Agrément Certificate

    Certificate type

  • QA Certificate

    Certificate type

Mannok Build

PIR foam wall insulation board.

Jump to:
+44 (0)28 6774 8866 www.mannokbuild.com
Application

  • Cavity walls: Insulation within timber frame.
  • Cavity walls: Internal dry lining fixed to plaster dabs.
  • Solid walls: Internal dry lining fixed to plaster dabs.
  • Pitched roof: Insulation below rafters.

Description

Polyisocyanurate (PIR) foam insulation board for walls. It is suitable for use in internal dry lining and in roofs beneath rafters on new build projects and refurbishment projects.

Features:

  • Low emissivity paper facing improves the thermal performance of the wall/ roof and enhances the thermal performance of the application.
  • Low thermal conductivity.
  • A+ BRE Green Guide rating.
  • Zero ODP.
  • Global warming potential of <5.
  • CE marked to BS EN 13165.

Applications:

  • Cavity walls: Insulation within timber frame.
  • Cavity walls: Internal dry lining fixed to plaster dabs.
  • Solid walls: Internal dry lining fixed to plaster dabs.
  • Pitched roof: Insulation below rafters.

General information
Features

Low emissivity paper facing improves the thermal performance of the wall/ roof and enhances the thermal performance of the application

Low thermal conductivity

A+ BRE Green Guide rating

Zero ODP

Global warming potential of <5

CE marked to BS EN 13165

Material

Polyisocyanurate (PIR) foam adhered to plasterboard

Uniclass 2015
Pr_25_71_63_66 Polyisocyanurate (PIR) foam boardsPrimary
Specification data - Polyisocyanurate (PIR) foam boards
Product Reference

Mannok Therm Laminate Kraft - MLK

Thickness

29.5 mm

12.5 mm thick plasterboard.

34.5 mm

9.5 mm thick plasterboard.

37.5 mm

12.5 mm thick plasterboard.

42.5 mm

12.5 mm thick plasterboard.

50.5 mm

12.5 mm thick plasterboard.

62.5 mm

12.5 mm thick plasterboard.

72.5 mm

12.5 mm thick plasterboard.

82.5 mm

12.5 mm thick plasterboard.

92.5 mm

12.5 mm thick plasterboard.

Standard product features

Material:

Polyisocyanurate (PIR) foam adhered to plasterboard.

Facing:

Bonded composite kraft paper on both sides.

Edges:

Butt.

Board size (l x w):

2400 x 1200 mm, 2438 x 1200 mm or 2743 x 1200 mm dependent on thickness.

Technical properties:

  • Thermal conductivity: 0.022 W/mK.
  • Core water vapour resistivity: 300 MNs/g (approximate).
  • Compressive strength: >150 kPa.
  • Dimensional stability (to BS EN 1604): DS(TH)4.
  • Fire rating: To BS 476-7: Class 1; To BS EN 13501-1: B-s1, d0.

Third party certifications
  • 07/4444
  • IAB: 05/0223, 07/0273
  • Certification Europe: ISO 9001, Client Reg 2005/262, Cert Ref, A/4
  • Certification Europe: ISO 14001, Client Reg 2008/502, Cert Ref, A/4
