Lumin Plywood - Plywood panels

Name: Lumin Plywood - Plywood panels
Brand: James Latham
SKU: cW7VAzCpaRyr24gAeHHQUx

Verified by manufacturer 12 days ago

Plywood panels.

Jump to:

Application

Suitable for:

Features and benefits:

Length	2440 mm
Width	1220 mm

Uniclass	Pr_25_71_97_33 General and utility veneer plywoodsPrimary
CAWS	K13/150 Purpose-made K30/10 Relocatable partition system K30/130 Relocatable partition system K32/112 Fully framed panel cubicles K32/120 Panel cubicles K32/130 Privacy screens K32/140 Duct/ wall linings – panels only K32/150 Duct/ wall linings – panels and proprietary frames K32/160 Duct linings – preplumbed panels and proprietary frames N10/10 Purpose-made N10/110 Purpose-made N10/160 Shelving systems N10/30 Shelving systems N11/380 Purpose-made units N12/440 Purpose-made

Product range	Panels

Sheet size	2440 x 1220 mm.
Nominal thickness	12 mm. 15 mm. 18 mm.

Panel Type	Eucalyptus (hardwood). Pine. Manufacturer guidance Panel type: - Grades: BCX: Clear “B” Pine face with minor repairs. 150 grit sanded front. C grade back, 100 grit sanded. CCX PTS: Repaired 'C' Pine or Eucalyptus face 120 grit sanded front. C grade unrepaired back, 80 grit sanded. Manufactured in accordance with EN 13986, EN 636-2-s and EN 314-2, Class 3. CE-marked. CDX: Pine or Eucalyptus face 'C' grade unsanded and unrepaired. Back 'D' face. Manufactured in accordance with EN 13986, EN 636-2-S and EN 314-2, Class 3. CE-marked. TRP: Clear 'B' Eucalyptus face. 120 grit sanded front, 100 grit sanded back. Limited open defects. Excellent substitute for tropical plywood in most applications. TRP faces are >3 mm thick, whereas most faces of 'tropical' plywood have faces of <0.5 mm. See manufacturer's literature for suitability of grades to certain applications.
Adhesive	Phenolic adhesive, made from phenol formaldehyde.
MoistureContent	6-10% (stabilized).
