Longboard® Panelboard

Name: Longboard® Panelboard
Brand: Longboard Products
SKU: irfU56ZEVwQokVbeGyUFSg

Verified by manufacturer 24 days ago

Longboard Products

Third party certifications:

EPD
Certificate type
UKAS
Certificate type
Declare
Certificate type

Extruded aluminium closed joint rainscreen panelized siding system.

Jump to:

+44 2039911138 Website

Application

For use as a closed joint rainscreen panelized siding system.

Description

Longboard® Panelboard is an extruded aluminium closed joint rainscreen panelized siding system, designed to be installed horizontally or vertically. Planks are available in standard lengths of 24’ (7.3 m) and a single width of 6” (152.4 mm). Components used for perimeter terminations, corners and panel trims are available in 12’ (3.7 m) lengths for most, with some in 24’ (7.3 m) lengths.

Features and benefits:

High impact strength.
100% recyclable, the extrusion does not contain any plastic elements.
Easy to maintain and cost-effective field repairs. Dirt and debris can be easily rinsed and washed off with a mild detergent depending on frequency of build-up. No caulking or glue is required for the product.
Rain-screen - BV/D (rear ventilated rain-screen), mechanical seals are used such as metal flashing and metal furring strips which are long-lasting.
Flatness.
Ease of installation.

General information

Color Black, Blue, Bronze, Brown, Grey, Red, White Oak, Dark Cherry, Mahogany, Charcoal, Copper Penny, Walnut, Italian Rosewood.	Bronze Blue Black Brown Copper Grey Red Beige Show more
Finish Consult manufacturer and insert requirement.	Gloss Powder-coated
Material	Aluminium
Shape	Rectangle
Length	7315.2 mm
Height	152 mm
Warranty description	15 year 20 year 50 year

Uniclass	Pr_25_71_51_06 Aluminium traditional sheetsPrimary
CAWS	H72/130 Aluminium sheet fully supported wall covering

Product range	Linear Metal Siding

Specification data - Aluminium traditional sheets

Factory finishes	Powder coated.
Thickness Base metal thickness.	1.52 mm.

Colour Consult manufacturer and insert requirement.	Black Blue Bronze Brown Grey Red White Oak Dark Cherry Mahogany Charcoal Copper Penny Walnut Italian Rosewood. Show more
Accessories	Not required. ¾” panelboard U-channel. ¾” panelboard U-channel end sleeve. ¾” U-cap and base. 1-1/2” U-cap and base. 1-1/2 panelboard U-channel. 1-1/2” panelboard U-channel end sleeve. End trim snap-cap. Finish cap/ finish base. J-Track. Quick screen clip. Single piece inside corner. Single piece outside corner. Starter. Two-piece reversible corner. Show more
Profile	152.4 mm. 6".
Length	7315.2 mm. 24 ft.
Material	Aluminium alloy 6063-T5.
Gloss level	30 (±5).
Fixing	Components are hard-fastened every 16” (406mm) directly through the flange. Planks are secured using Longboard Quick-Screen Clips fastened to the substrate with screws. #8 pan-head self-drilling screws (not included) are recommended.

Sustainability data

Contains Red List materials	No
Country of material origin	Canada
Country of product manufacture	Canada
Embodied carbon A1-A3 (production stage) as defined in BS EN 15804	6.75 kg CO₂ eq/kg
Recyclability	100 100% recyclable, the extrusion does not contain any plastic elements.
Recycled content	50 %
