Longboard® 1 x 5" Beam End Frame System

Longboard® 1 x 5" Beam End Frame System

Verified by manufacturer 1 month ago

Longboard Products Third party certifications:
  • UL Certified EPD

    Certificate type

  • Declare

    Declare

    Certificate type

  • UKAS

    UKAS

    Certificate type

1 x 5" aluminium siding/ privacy beams providing a framed appearance.

Jump to:
+44 2039911138 www.longboardproducts.com

Application

Suitable for use as siding/ privacy beams and compliments any building design.

Description

Aluminium siding/ privacy beams with a 1 x 5" profile, providing a framed appearance.


Features and benefits:

  • Built for easy installation, low-maintenance and durability.
  • Can be installed horizontally or vertically.
  • Available in woodgrain, solid and shimmer colour options. Custom colours are also available.
  • 15 year warranty. 20 year ultra-warranty available for additional cost; consult manufacturer for details.

General information

Color

Black

Blue

Bronze

Brown

Copper

Show more

Finish

As per manufacturer and includes:

  • Woodgrain.
  • Solid.
  • Shimmer.

Gloss

Powder-coated

Material

Aluminium

Shape

Rectangle

Length

7315.2 mm

Width

25.4 mm

Height

127 mm

WarrantyDescription

15 year

20 year

Ultra-warranty available for additional cost; consult manufacturer for details.

50 year

Uniclass

Pr_25_71_51_06 Aluminium traditional sheetsPrimary

CAWS

H72/130 Aluminium sheet fully supported wall covering

Specification data - Aluminium traditional sheets

Factory finishes

Powder coated.

Thickness

Bare metal thickness.

0.062 mm.

Colour

Custom colours are also available; consult manufacturer for more information.

Western cedar.

Dark cherry.

Light cherry.

Dark fir.

Light fir.

Show more

Accessories

Not required.

Beam caps.

Double posts.

Flat bar spacers.

Mounting brackets.

Show more

Profile

25.4 x 127 mm.

1 x 5".

Length

7315.2 mm.

24 ft.

Material

Extruded aluminium 6063-T5.

Gloss level

30 (±5).

Environmental information

Contains Red List materials

No

Country of material origin

Canada

Country of product manufacture

Canada

Embodied carbon

6.75 kg·CO₂e/kg

Recyclability

100%

Recycled content

50 %

Digital objects

Platform Compatible Version Certified to
Revit
-

1

1

Download now from NBS National BIM Library

Literature

Dauntless Curve Submittal

Dauntless Curve Submittal

Dauntless Align Submittal

Dauntless Align Submittal

ICC-ES Evaluation Report Siding

ICC-ES Evaluation Report Siding

Intrepid Grill Submittal

Intrepid Grill Submittal

Intrepid Stellar Submittal

Intrepid Stellar Submittal

Link & Lock - Siding

Link & Lock - Siding

Longboard Acoustical NRC Rating for 6" Link + Lock with Insulation

Longboard Acoustical NRC Rating for 6" Link + Lock with Insulation

Longboard LEED v4.1 - Interior Systems

Longboard LEED v4.1 - Interior Systems

Longboard Colour Chart Brochure

Longboard Colour Chart Brochure

Longboard Link & Lock

Longboard Link & Lock

Longboard Privacy Beams

Longboard Privacy Beams

Longboard Product Brochure

Longboard Product Brochure

Longboard 15 year Warranty

Longboard 15 year Warranty

Privacy Beams - Siding Submittal

Privacy Beams - Siding Submittal

UK Fire Testing

UK Fire Testing

Case studies

Janzen Insurance

Janzen Insurance

Restaurant Facade

Restaurant Facade

Suspended Ceiling System - Equinox Gym

Suspended Ceiling System - Equinox Gym

Third party certifications

UL Certified EPD

UL Certified EPD

Environmental Product Declaration

Declare

Declare

Longboard Declare Label

UKAS

UKAS

UK Fire Testing
