(LGSF) Light Gauge Steel Frame Structural Solutions (up to 15 storeys)

Light gauge steel frame structural solutions for Low & Medium Rise projects up to 15-storeys:

Remagin's light to medium-duty steel frame solutions are perfect for low and mid-rise developments up to fifteen storeys high. They especially excel in urban spaces with limited room, and their pre-assembled nature means construction programmes can be accelerated significantly. Built by precision manufacturing in factory conditions, and rapid to assemble on site, Remagin’s light steel framing systems offer superior safety and comfort levels, as well as high energy performance levels, for residents.

Walls:

100mm bespoke light steel framing solution available with a variety of configurations including wall type, fire performance, sound insulation rating, insulation and boards.

Stairs: Standard 1200 mm wide option

Prefabricated steel stairs comprising, 1200 mm wide 3 mm thick folded plate treads together with bonded 25 mm CP board with flat steel stringers, together with 180 mm thick composite concrete metal deck half landings. Other tread options are available if required

Stairs: 1500 mm wide option

Prefabricated steel stairs comprising, 1500 mm wide 3 mm thick folded plate treads together with bonded 25 mm CP board with flat steel stringers, together with 180 mm thick composite concrete metal deck half landings. Other tread options are available if required

Intermediate Floors

180 mm deep C32/40 concrete on Remagin Sig-Deck, pre-cambered, crushed end trapezoidal decking, including all necessary designed reinforcement to meet fire regulations and progressive collapse.

Roof: Concrete Option

180 mm deep C32/40 concrete on Remagin Sig-Deck, pre-cambered, crushed end trapezoidal decking, including all necessary designed reinforcement to meet fire regulations and progressive collapse. Supporting beams and tophat sections dropped to allow for continuous slab at roof level helping water management and follow-on trades.

Roof:

Trapezoidal profile galvanized steel roof decking supplied in double span lengths supported on LGSF purlins, purlins depths and section sizes to suit span requirements.
