Glass laminated using green coloured PVB interlayer to provide safety, security and improved acoustic performance.
Guardian laminated safety glass colour is a combination of two or more panes of glass with one or more coloured polyvinyl butyral (PVB) layers. This can be adapted to many aspects of modern window design, such as solar control, noise reduction, privacy, thermal insulation and energy conservation, whilst ensuring safety and security in a wide variety of situations. LamiGlass Colour can also be used to help characterise interior design through a variety of applications.
Further processing:
Benefits:
Applications:
Standards:
Guardian Europe has ISO 9001 accreditation for the manufacture of float glass at all of its European based float glass plants. Guardian LamiGlass complies with the requirements of EN 14449: 2005 ‘Glass in Building: Laminated Glass and Laminated Safety Glass’. Guardian also has ISO 14001 Environmental Management System standard.
Features | Break safe characteristics, resists attack, UV protection |
Uniclass 2015 | |
CAWS | H10/10 Patent glazing H10/115 Patent glazing H11/110 Curtain walling H13/115 Structural glass assembly L40/210 Putty-fronted single-glazing L40/230 Bead-fixed single-glazing L40/250 Bead-fixed single-glazing L40/260 Bead-fixed single-glazing L40/310 Bead-fixed single-glazing L40/330 Bead-fixed single-glazing L40/350 Bead-fixed single-glazing L40/370 Bead-fixed insulating glass units L40/371 Bead-fixed insulating glass units L40/372 Bead-fixed insulating glass units L40/380 Bead-fixed insulating glass units L40/381 Bead-fixed insulating glass units L40/40 Putty-fronted single-glazing L40/410 Single-glazing into grooves L40/430 Single-glazing into grooves L40/450 Single-glazing into grooves L40/470 Zipper gasket glazing L40/490 Single-sided gasket glazing L40/50 Bead-fixed single-glazing L40/530 Internal tape glazing L40/55 Bead-fixed insulating glass units L40/57 Bead-fixed insulating glass units L40/58 Bead-fixed insulating glass units L40/90 Internal tape glazing |
Product Reference | LamiGlass® Colour |
Thickness | 6.4 mm6.8 mm8.4 mm8.8 mm10.4 mm10.8 mm12.4 mm12.8 mm |
Interlayer | 2165 White (Opal/diffuse)Core colour. 6544 GreyCore colour. 3628 BronzeCore colour. 5558 Light BronzeCore colour. 3773 GreenCore colour. 0828 Blue GreyColour available subject to minimum order. 3609 Dark BrownColour available subject to minimum order. 3628 Neutral BrownColour available subject to minimum order. 3773 Blue GreenColour available subject to minimum order. 5538 Light BronzeColour available subject to minimum order. 6376 Cool BlueColour available subject to minimum order. 6428 Mid BronzeColour available subject to minimum order. 7558 Sky BlueColour available subject to minimum order. |
Standard product features | Glass type: ExtraClear float. Size: - Manufacturer's standard (other sizes available):
|
Product Options | Thickness/ Interlayer: LamiGlass® Colour may be available to satisfy other performance requirements, made up of a variety of additional thicknesses or number of PVB interlayers – consult manufacturer for suitability. |
Platform | Compatible | Version | Certified to |
---|---|---|---|
![]() | Revit 2016 | 4 | 2.0 |
![]() | IFC2X3 | 3 | 1.3 |
