Koster TPO Aqua - Water tank lining system

Verified by manufacturer 2 months ago

Koster Aquatecnic Ltd Third party certifications:
  • EPD

    EPD

    Certificate type

TPO single ply membrane for the internal waterproofing and lining of water tanks.

Jump to:
+44 (0)1387 270252 Website

Application

This hot air welded membrane can be used to line water tanks, reservoirs, artificial ponds and lakes, fishponds and swimming pools.

Description

The Koster TPO Aqua membrane offers excellent application characteristics including flexibility and weld-ability and does not contain any harmful migratory plasticisers or PVC.


Lining of water tanks using the Koster TPO Aqua membrane is the safe, clean, and reliable way of ensuring water is permanently contained within the structure. The Koster TPO Aqua doesn’t require intensive preparation prior to installation, thus reducing additional labour and material costs compared to a liquid application. The membrane carries European drinking water certification for situations when potable water is intended to be stored.



Following a straightforward preparation:



"All substrates should be designed to resist the positive pressures of the water being contained inside however, application onto reinforced concrete, precast concrete, block, brick, metal and even timber is possible. All application surfaces should be smooth and free of harsh edges, depressions, or any other abnormalities that could puncture the membrane once installed. Cracks (non-structural), old paints/coatings and membranes are admissible."



A 500 g/sqm geotextile matting is loosely placed onto the tank floor, this ensures any undulations in the slab won't stress the installed membrane, followed by overlaying with the desired Koster TPO Aqua. Mechanical fasteners are installed around the room perimeter securing the membrane in place.



Further rolls of Koster TPO Aqua are then applied to the walls, either horizontally or vertically and held in place with suitable membrane washers and screws. Overlaps between sheets to be 110 mm. At the uppermost point on the tank walls, a strip of Koster TPO Laminate metal is to be mechanically fixed thus allowing a suitable welded termination for the membrane.



All overlaps, terminations and detailing should be fully hot air welded as per the guidelines in the Koster TPO Installation guide. Approved contractor installation only. Please contact the Koster technical team for recommended contractors.



Features and benefits:

  • European drinking water approval.
  • PVC free.
  • Fully mechanically fixed.
  • Non-intensive preparation.
  • UV stable.
  • All joints are fully hot air welded.
  • Environmentally friendly and recyclable.
  • High flexibility.
  • Excellent resistance against mechanical damage.
  • Suitable with most substrates.



All projects are detailed by the Koster Technical team. For design advice or further information, please contact technical@kosteruk.com.

General information

Color

Grey

Finish

Smooth

Material

Thermoplastic elastomer (TPE)

Shape

Rectangle

Other

Length

20000 mm

Width

1500 mm

Height

1.5 mm

Warranty description

Ten year

Uniclass

Ss_32_80_90_85 Structure-supported water retention sheet lining systemsPrimary

CAWS

J40/297 Waterproofing/ damp-proofing/ gas-retardant membrane

J44/110 Geomembrane lining

Product range

Internal Basement Waterproofing Systems
Civil Engineering Systems
Roofing Systems

Specification data - Structure-supported water retention sheet lining systems

Substrate lining sheets

None.

500 g/sqm geotextile matting.

Water retention sheets

-

Material

Thermoplastic polyolefin elastomer (TPE).

Jointing

Hot air welded at all overlaps and details, as per Koster approved guidelines.

Surface protection sheets

Koster TPO Maintenance Walkway membrane.

Top edge support

-

Method

Mechanically fastened.

Fixings and fasteners

TPO laminated metal, mechanically fastened every 20 cm on vertical wall termination and 25 cm for horizontal top edge termination.

Sustainability data

Contains Red List materials

No

Country of material origin

Germany

Country of product manufacture

Germany

Recyclability

Yes

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

100 %

Third party certifications

Third party certifications

EPD

Koster TPO Roofing Membrane Environmental Product Declaration
