Knauf Contur - Monolithic Looking, Demountable Ceiling

Guidance for specification option:

Insert drawing reference number.

Guidance for specification option:

• A reinforcement panel of sufficient strength can be installed behind the tile.
• The reinforcement panel must extend all the way into the main runners, so that the weight is transferred to them.
• The total weight should not be greater than 3 k.g. for each m² of ceiling.
• Where loads are greater than 3 k.g./m², additional hangers must be used.
• Units over 3 k.g., should be installed independently, so that they do not place any load on the ceiling.

Insert additional requirements; contact manufacturer for more information.

Guidance for specification option:

Insert requirements; contact manufacturer for more information.

Guidance for specification option:

• White water-based acrylic paint, RAL 9003, gloss 5.
• Recommended to use white gloves while installing.

Guidance for specification option:

Depending on perforation design in accordance with DIN 5036.

Guidance for specification option:

Insert drawing reference number.

Guidance for specification option:

• Suspension hangers: Knauf adjustable ceiling hangers at 1200 mm centres (first angle maximum 100 mm from wall, type of hanger depends on installation depth).
• Primary support channel: Knauf 38 mm deep T-24 primary runner at 600 mm centres (first runner maximum 600 mm from wall).
• Spacer bars: Knauf spacer bars fitted to primary channels every 1200 mm (maximum 1500 mm).
• Perimeter channel: Use Knauf 20 X 24 mm wall angle or Knauf MS15 shadow line trim (creating 15 mm shadow gap) fixed at 300 mm centres.

Insert additional requirements; contact manufacturer for more information.

Guidance for specification option:

Fixings are used to meet performance constraint confirmation is required from supplier to meets ceiling specification and any additional loading.

Insert requirements; contact manufacturer for more information.
