Knauf AMF Topiq Prime
Application

For use with the following Knauf AMF suspended ceiling systems: System C: exposed Ventatec grid system, demountable ceiling.

Description

Ceiling tile with acoustic sound absorption, combining technical properties with simple elegance.


Features and benefits:

  • Offers Class A sound absorption.
  • High humidity resistance.
  • Good sound attenuation.

General information

Finish

Fleece

Color

White

Similar to RAL 9010.

Material

Fibre

Shape

Square

Rectangular

Size

600 x 600 x 15 mm

600 x 1200 x 15 mm

WarrantyDescription

Uniclass 2015

Pr_35_93_13_53 Mineral fibre infill unitsPrimary

CAWS

K40/10 Suspended ceilings

K40/105 Suspended ceiling system

Specification data - Mineral fibre infill units Enhanced data

Unit type

Fibre ceiling tile.

Material

Fibre.

VOC emissions

0%.

Recycled content

28.69.

Unit size

-

Face dimensions

600 x 600 x 15 mm thick.

SK square edge; 15 or 24 mm exposed Ventatec grid system.

600 x 1200 x 15 mm thick.

SK square edge; 15 or 24 mm exposed Ventatec grid system.

600 x 600 x 15 mm thick.

VT-S-24 rebated edge; 24 mm exposed Ventatec grid system.

600 x 1200 x 15 mm thick.

VT-S-24 rebated; 24 mm exposed Ventatec grid system.

600 x 600 x 15 mm thick.

 VT-S 15 rebated edge; 15 mm exposed Knauf AMF grid system.

600 x 600 x 15 mm thick.

VT-S 24 rebated edge; 15 mm exposed Knauf AMF grid system.

Thickness

15 mm.

Surface texture

Pronounced, directional fissured surface, giving acoustic absorption.

Colour

White.

Similar to RAL 9010.

Edge profile

Square.

Rebated.

Perimeter trim

Not required.

A-RWL.

24 x 24 mm angle.

I-RWL.

31 x 31 mm angle.

C-SRW shadow angle.

20 x 20 x 20 x 20 mm, 25 x 15 x 8 x 15 mm.

I-SRW.

25 x 15 x 10 x 15 mm shadow angle.

Fire safety

Complies with BS EN 13501-1: Class A1.

Sound absorption

To BS EN ISO 354: aw 0.95 as per EN ISO 11654. Sound absorption Class: A.

RelativeHumidity

90%.

(maximum).

Light reflectance

Up to 88%.

Weight

2.1 kg/m².

Sound attenuation

Rating to EN 10848 Dn,f,w: 24 dB.

Sound insulation

Rw = 15 dB as per EN ISO 10848.

Anti-microbial treatment surface finish (Hygena)

Not required.

Required.

Cleanroom classification

Class 4 as per ISO 14644-1.

Environmental information

Contains Red List materials

No

Country of material origin

Germany

Recyclability

100%

Recycled content

28.69

Literature
Third party certifications
  • Regulation (EC) No 1272/2008: RAL-GZ certified
