Knauf AMF Thermatex Plain Hygena

Knauf AMF Thermatex Plain Hygena

Knauf AMF Ceilings Ltd Third party certifications:
  • QA Certificate

    QA Certificate

    Certificate type

Ceiling tile with fire protection and acoustical physical properties meeting healthcare facility-level requirements.

Jump to:
+44 (0)191 518 8600 www.knaufamf.co.uk
Application

Can be used with A-RWL, I-RWL, C-SRW shadow angles and I-SRW perimeter trims.

Description

A ceiling tile meeting healthcare facility-level fire protection and acoustics physical property requirements. Comes with specially developed antimicrobial hygena treatment. An ideal acoustic tile choice for addressing health, cleanliness and hygiene issues.


Features and benefits:

  • Designed for use with Knauf suspended ceiling system C.
  • Available for use on 15 mm and 24 mm Knauf grid.
  • Available for use as SK on 24 mm Knauf grid.
  • Fleece offers a smooth surface finish.
  • Fully demountable.

General information

Finish

Smooth

Color

White

Similar to RAL 9010.

Material

Mineral fibre

Shape

Square

Size

600 x 600 mm

WarrantyDescription

Uniclass 2015

Pr_35_93_13_53 Mineral fibre infill unitsPrimary

CAWS

K40/10 Suspended ceilings

K40/105 Suspended ceiling system

Specification data - Mineral fibre infill units Enhanced data

Unit type

High performance mineral ceiling tile with SF Shadow Edge detail. Exposed Ventatec grid system.

Material

Mineral fibre.

VOC emissions

0%.

Recycled content

48.86.

Unit size

-

Face dimensions

600 x 600 mm.

Thickness

24 mm.

Surface texture

The fleece offers a smooth surface finish.

Colour

White.

Similar to RAL 9010.

Edge profile

Square.

Product Reference

Knauf AMF Thermatex Plain Hygena

Perimeter trim

Not required.

A-RWL.

24 x 24 mm angle.

I-RWL.

31 x 31 mm angle.

C-SRW shadow angle.

20 x 20 x 12 x 20 mm.

Fire safety

BS EN 13501-1: Class A2-s1, d0.

Sound absorption

To BS EN ISO 354: αw 0.65 (H). Sound absorption Class: C. Noise reduction coefficient (NRC) to ASTM C 423-02a: 0.70.

Weight

8.4 kg/m².

RelativeHumidity

95%.

(maximum).

Fire protection

To BS 476-20 to -23 (maximum): 60 minutes.

Light reflectance

85%.

 (maximum).

Sound attenuation

To EN ISO 10848 Dn,f,w: 39 dB.

Cleanroom classification

Class 4 as per ISO 14644-1.

Anti-microbial treatment surface finish (Hygena)

Not required.

Required.

Environmental information

Contains Red List materials

No

Country of material origin

Germany

Recyclability

100%

Recycled content

48.86

Literature
Third party certifications
  • Der Blaue Engel: Certified
  • Regulation (EC) No 1272/2008: RAL-GZ certified
