Keyblok Vintage - Rectangular Block Paver
Verified by manufacturer 2 months ago
200 x 100 mm rectangular block paver.
Application
For applications up to and including heavy duty.
Description
A 200 x 100 mm rectangular block paver.
Features and benefits:
- Standard to BS EN 1338: 2003.
- 200 x 100 mm rectangular block paver with lightly distressed edges and integral spacers.
- 60 mm-thick blocks are suitable for general duty, 80 mm-thick for applications up to and including heavy duty.
General information
Color | Red Brown Grey Manufacturer guidanceBracken, Brindle, Burnt Ochre, Charcoal. |
Material | Concrete |
Shape | Rectangle |
Length | 200 mm |
Width | 100 mm |
Height | 80 mm |
Uniclass | |
CAWS | Q24/10 Conventional concrete block paving Q24/110 Conventional concrete block paving Q24/112 Conventional concrete block paving with bound base Q24/113 Conventional concrete block paving overlay |
Specification data - Concrete paving blocks
Standard | To BS EN 1338. |
Physical properties | |
Colour | Bracken.Brindle.Burnt Ochre.Charcoal. |
Finish | Guidance for specification option: A number of different surface profiles are available. |
Dimensions and associated tolerances | |
Nominal sizes | 200 x 100 x 60 mm.200 x 100 x 80 mm. |
Weathering resistance | ≤1.0 kg/m² as a mean with no individual value > 1.5 kg/m² (freeze thaw durability).Guidance for specification option: It should be appreciated that with all products weathering and site conditions can cause shade variation to appear across the surface of individual units. This does not in any way affect the performance of the units and any such variation will diminish over a period of time as the product matures |
Abrasion resistance | ≤23 mm (wide wheel abrasion test). |
Slip resistance | > 45.Guidance for specification option: Mean polished skid resistance value (PSRV): > 45, Mean unpolished skid resistance value (USRV): > 45 |
Skid resistance | > 45.Guidance for specification option: Mean polished skid resistance value (PSRV): > 45, Mean unpolished skid resistance value (USRV): > 45 |
Sustainability data
Contains Red List materials | No |
Embodied carbonA1-A3 (production stage) as defined in BS EN 15804 | 15 kg CO₂ eq/m² Self declared |
