Kent Hidden Fixing Corner Guards
Description

Corner guards with hidden fixings, designed to protect walls from impact.

Features and benefits:

  • Three-cornered profile provides maximum stability and rigidity whilst the raised edges provide a smooth, flush finish.
  • Satin finish 320 grit polished as standard.
  • Complemented by Kent wall-mounted bump rails (specified separately).
  • Can stand proud of or flush with tiled surfaces.
  • Easy to install and maintain.
  • Special orders available; consult manufacturer for details.

General information
Uniclass 2015
Pr_35_90_43_15 Corner guardsPrimary
CAWS

M40/10 Natural stone covering to

M40/110 Tiling to

M40/115 Natural stone covering to

M40/12 Mosaic to

M40/120 Mosaic to

M40/5 Tiling to

M41/110 Terrazzo tiling

M41/120 In situ terrazzo

M41/130 Precast terrazzo

M41/140 Marble tiling

N10/184 Wall rails

P20/170 Proprietary

P20/30 Proprietary

Specification data - Corner guards
Product Reference

Kent Hidden Fixing Corner Guards

Type

KHCG-50

Width: 50 mm.

KHCG-60

Width: 60 mm.

KHCG-70

Width: 70 mm.

KHCG-80

Width: 80 mm.

KHCG-90

Width: 90 mm.

KHCG-100

Width: 100 mm.

Material -
Type

1.4301 (304) stainless steel

Standard.

1.4401 (316) stainless steel

Thickness

2 mm

Standard.

3 mm

Material Finish

320 grit polished and electropolished

Bead blasted

Bead blasted and electropolished

Electropolished

Satin, 320 grit polished

Standard.

Powder coated

Insert colour requirements.

Standard product features

Length:

1000 mm.
