Kaleidoscope

Name: Kaleidoscope
Brand: Karndean Designflooring
SKU: 31fjAVeq1QdKNmdyhuHPqS

Verified by manufacturer 4 months ago

Kaleidoscope 2.5 mm

Luxury vinyl flooring individually cut from established wood and stone vinyl designs featuring a wide array of hues, geometric shapes and patterns.

Jump to:

+44 (0)1386 820104 Website

Description

Kaleidoscope is a collection of wood, stone and block colours available in eight geometric designs including Cubix, Pennon and Apex. The palette of wood, stone and solid colours can be cut in a number of popular shapes and patterns, offering full flexibility at the point of specification.

Individual shapes are cut from Karndean products so that they retain the designs and key technical specifications including slip resistance, wear layer and light reflectance value (LRV). With over 100 different colours to choose from, the precise technical specification will depend on the final selection specified.

General information

Color	- Manufacturer guidance 100 colours available.
Material	Polyvinyl chloride (PVC)
Length	- Manufacturer guidance Various sizes available. Please consult manufacturer for details.
Width	- Manufacturer guidance Various sizes available. Please consult manufacturer for details.
Warranty description	20 year Guidance for specification option: Light industrial: 20-year. Commercial: 20-year. Lifetime Guidance for specification option: Residential: Lifetime guarantee.

Uniclass	Pr_35_57_71_68 Polyvinyl chloride (PVC) tilesPrimary
CAWS	M50/10 Resilient floor tiling M50/110 Resilient floor tiling

Specification data - Polyvinyl chloride (PVC) tiles

Standard	To EN 649 and EN ISO 10582.
Use class	To EN 685/EN ISO 10874, class 23. Guidance for specification option: 2.5 and 3 mm thickness. 23: Domestic heavy. To EN 685/EN ISO 10874, class 33. Guidance for specification option: 2.5 mm thickness. Commercial heavy. To EN 685/EN ISO 10874, class 42. Guidance for specification option: 2.5 mm thickness. 42: Light industrial general.
Slip potential	-
Slip resistance value (SRV) (minimum)/ Pendulum test value (PTV) (minimum)	R10; DS. Guidance for specification option: To DIN 51130: R10; to EN 13893: DS.
Size	- Manufacturer guidance To EN ISO 24342. Various sizes available.
Thickness	2.5 mm. Guidance for specification option: To EN ISO 24346.

Type	Guidance for specification option: Various options available, consult manufacturer and insert requirements.
Wear layer thickness	0.55 mm. Guidance for specification option: 2.5 mm thickness. To ISO 24340.
Surface treatment	K-Guard+ PU coating.
Mass	5220 g/m². Guidance for specification option: To EN ISO 23997.
Reaction to fire	Bfl-s1. Guidance for specification option: To EN 13501-1.
Lightfastness	≥6. Guidance for specification option: To EN ISO 105-B02.
Abrasion resistance	Group T; Type 1. Guidance for specification option: To EN 660-2: Group T; to EN ISO 10582: Type 1.
Dimensional stability	≤0.25%. Guidance for specification option: To EN 434.
Sound reduction	2 dB. Guidance for specification option: To EN ISO 717-2/ EN ISO 140-8: ΔLw = 2 dB.
Residual indentation	Pass. Guidance for specification option: To EN 433.
Castor chair rating	Pass. Guidance for specification option: To EN 425.
Thermal resistance	0.0097 m²K/W. Guidance for specification option: 2.5 mm thickness. To ISO 8302/EN12664. Suitable for underfloor heating maximum 27°C.
VOC emissions	A+. Guidance for specification option: To ISO 16000.
LRV	12. Guidance for specification option: To BS 8493:2008+A1:2010. Available in 2.5 mm (V18). 13. Guidance for specification option: To BS 8493:2008+A1:2010. Available in 3 mm (V6) and 2.5 mm (V16) 21. Guidance for specification option: To BS 8493:2008+A1:2010. Available in 2.5 mm (V12). 24. Guidance for specification option: To BS 8493:2008+A1:2010. Available in 2.5 mm (V13 and V19). 29. Guidance for specification option: To BS 8493:2008+A1:2010. Available in 2.5 mm (V17). 36. Guidance for specification option: To BS 8493:2008+A1:2010. Available in 2.5 mm (V15). 41. Guidance for specification option: To BS 8493:2008+A1:2010. Available in 2.5 mm (V11). 52. Guidance for specification option: To BS 8493:2008+A1:2010. Available in 2.5 mm (V14). 71. Guidance for specification option: To BS 8493:2008+A1:2010. Available in 2.5 mm (V20). Show more

Sustainability data

Recyclability	Suitable for recycling

BIM objects

Platform	Compatible	Version
Revit	-	1

Literature

Light Reflectance Values

Kaleidoscope Installation Guidelines

Kaleidoscope Brochure

Solid Colours Technical Data Sheet

Opus Technical Data Sheet
